A branch fitting is used to create internally reinforced connections from the run pipe to the outlet pipe between 45 and 90 degrees. A Weldolet Fitting is a popular branch fitting that is part of the butt-weld fitting family. These fittings are welded onto the outlet to the run pipe and are used in higher pressure applications. The Astm A105 Weldolet is a forged grade that connects the pipe to minimize the stress on the grade. These items have a similar or higher schedule than the schedule on the run pipe. Asme B31.3 Weldolet helps convey fluids at pressures as per the limits seen in petroleum refineries and other industries. The A234 Wpb Weldolet covers standard carbon and alloy steel material that can be produced in seamless and welded types. A weldolet is available in a dimension range between ¼ to 36 inches. An Mss Sp 97 Weldolet covers material with dimensions, finish, testing, and tolerance of integrally reinforced branched outlet fittings. A Class 3000 Weldolet can hold nominal pressure of 2000psi with a maximum test pressure of 3000psi. Our company is a Weldolet manufacturer in India that follow all standards of the local and international legislature to produce the best products in the industry.

A Stainless Steel Weldolet is designed possessing excellent corrosion resistance properties and can work across a range of pressure and temperature conditions. The Carbon Steel Weldolet has a higher content of carbon in its composition, allowing it to showcase moderate strength and corrosion resistance properties across the system. Aluminum Weldolet is a soft lightweight grade that is very ductile and can be shaped in different sizes. The weldolet is comparatively expensive when compared to steel having the same strength.

Biggest Supplier of Aluminum Weldolet in Mumbai, Leading Stockist of Stainless Steel Weldolet

Weldolet Specification

Connect Type Bevelled and Welded
Dimensions MSS-SP-97, ASME B31.3, B31.1, B31.8, B31.4, ASME/ANSI B16.11
Thickness Schedule 5S to120S
Size From 1/8″to 24″
Class 6000LBS, 3000LBS, 9000LBS

ANSI B16.11 Weldolet Price List

Description Price Per Kg In Singapore Price Per Kg In UAE Price Per Kg In USD Price Per Kg In Malaysia
Sch 160 3/4 Inch x 1 Inch - 36 Inch Forged Fittings Weldolets SGD 7.43 UAE Dirham 19.41 US $5.37 MYR 23.54
OD 108 X 30 X 5.0 X 2.5 T CUPRO-NICKEL ALLOY FITTINGS WELDOLET SGD 32.27 UAE Dirham 84.27 US $23.31 MYR 102.20
2 X 16SCH 80/XS PIPE FITTING CARBON STEEL GR SA350 LF2 WELDOLET CS CL1 FORGED ASME B31.1/B31.3/MSS SP-97 SGD 30.82 UAE Dirham 80.46 US $22.26 MYR 97.58
10 X 1.125MW X 4SCH 160 PIPE FITTING ALLOY STEEL P91 A182 WELDOLET SGD 834.46 UAE Dirham 2,178.87 US $602.67 MYR 2,642.46
20 3 THK 68.28 MM X SCH XXS WELDOLET ASME SA 182 GR F91 BEVELLED END MSS-SP-97 SGD 111.22 UAE Dirham 290.41 US $80.33 MYR 352.20
38 3 THK 32.95 MM X SCH STD WELDOLET ASTM A182-GR F91 BEVELLED END MSS-SP-97 SGD 155.84 UAE Dirham 406.93 US $112.55 MYR 493.51
