Hastelloy C276 Pipe Fittings

UNS Designation :

• UNS N10276

Type of Steel :

• Nickel Molybdenum Chromium Alloy

Corrosion Resistance :

• Sulfuric Acids

Suitable For :

• Power Generation

Advantage :

• Excellent Corrosion Resistance

Also Called :

• King Of Corrosion Resistant Alloys

Process :

• Hot Forging & CNC Machined

Standard :

• ASTM B366

Testing :

• Hardness Test

Size In Ready Stock :

• Welded : 24" To 96"
• Seamless : 1/2" To 24"
• DIN15 To DN1500
• Buttweld : 1/2" To 36"
• Contact Hastelloy C276 pipe fittings manufacturer in India for above 48″

Machines :

• Portable Temperature Indicator
• Cold Forming Machines
• Hydraulic Press 150 Tons Capacity
• CNC Lath
• Beveling Machine
• Conventional Machine

Test Report :

• Raw material test reports
• Material traceability records
• Fumigation certificates

Wall Thickness :

• SCH 20 & 40
• SCH : 80 To 120
• SCH : 160 To 180

Manufacturing Standard :

• ASME B16.9

Available Packaging :

• Wooden Cases
• Carton Box
• Wooden Pallet

Melting Point :

• 1323°C To 1371°C

Density :

• 8.89 g/cm

Manufacturing Raw Material :

• Round Bar
• Seamless Pipe
• Welded Pipe

Advantages :

• Non Toxic

Forming Process :

• Hot Forming
• Cold Forming

UNS Number :

• UNS N10276

Temperature Range :

• 870°C To 1230°C

Heat Treatment :

• Solution = 2050°F

Method :

• Welded (Weld)
• Seamless (SMLS)
• Buttweld (BW)

DIN Number :

• WNR 2.4819

Thickness Tolerance :

• +/-12.5%
• Custom

Marking :

• Standard
• Heat Number
• Grade
• Material
• Size & Schedule
• Manufacturers Name

Material Life :

• 35 Years

Manufacturing Process :

• Heat Treated
• Forged
• Machined

Chromium Content :

• 14.5% To 16.5%

Elongation :

• 40%

Certificates :

• EN 10204 3.1
• EN 10204 3.2

Surface :

• Polished

Uses :

• Power Generation
• Oil and Gas
• Chemical Equipment
• Petrochemicals

Method:

• Forged
• Pushing
• Butt Weld
• Casting
• Welding

Testing Requirements :

• Hardness Test
• Mechanical Testing
• Hyrdrostatic Test
• Chemical Analysis
• PMI Test

Radius Of Pipe Bend :

• 1.5D/ 2D/ 3D
• 4D/ 5D/ 6D
• 8D/ 10D/ 22D

Angle Of Pipe Bend :

• 15 Deg, 22.5 Deg, 30 Deg
• 45 Deg, 60 Deg, 90 Deg
• 135 Deg, 180 Deg

Logistics :

• By Air
• By Sea
• UAE = 5 day
• Germany = 20 days
• Philippines = 14 days
• Malaysia = 10 days
• Saudi Arabia = 7 day
• Netherland = 30 day
• Belgium = 40 day
• France = 30 day
• South Africa = 30 days
• Uk = 30 day

Carbon [C] :

• 0.015% (Maximum)

Manganese [Mn] :

• 0.50% (Maximum)

Sulfur [S] :

• 0.03% (Maximum)

Silicon [Si] :

• 0.08% (Maximum)

Chromium [Cr] :

• 14.50% To 16.50%

Nickel [Ni] :

• 50.99% (Minimum)

Iron [Fe] :

• 4.00% To 7.00%

Phosphorus [P] :

• 0.04% (Maximum)

Grade :

• Hastelloy C276 Pipe Fittings

UNS :

• UNS N10276

WERKSTOFF NR. :

• WNR 2.4819

Japanese (JIS) :

• NW 0276

British (BS) :

• -

Russian (GOST) :

• ХН65МВУ

France (AFNOR) :

• -

European (EN) :

• NiMo16Cr15W

Density :

• 8.89 g/cm3

Melting Point :

• 2500°F

Tensile Strength :

• 790 MPa

Yield Strength :

• 355 MPa

Elongation :

• 40%

Specific Heat :

• 427 J/kg*°C

Magnetic Permeability :

• 1.0002 15.9 kA/m

Thermal Conductivity :

• 10.5 W/(mºC)

Electrical Resistivity :

• 1.23 μΩm
