Contact us to get latest price list of ASTM B62 UNS C36000 Tee, One of the best supplier of ASME SB62 Brass Elbow in Mumbai

Brass Fittings Manufacturers in India

Fittings help in connecting piping grades that can be routed, branched or their direction changed. These Brass Pipe Fittings are common fittings in the oil and gas industry that allows them to influence the characteristics of the media. These fittings have enhanced tolerance to reducing and corrosive affluents. The Brass Elbow allows for a smooth flow of media as they change the direction of the flow in the system. These elbows are generally produced in 45 and 90 degrees specifications. A Brass Tee is designed in the shape of a T. These tees allow for the mixing of media between the two channels received from the main line. They can be produced with equal and unequal specifications. A Brass Reducer helps in connecting piping diameters of unequal diameters. The reducer creates a gradual pressure drop and is available in eccentric or concentric specifications. Our institution is amongst the best Brass Fittings manufacturers in India who utilize the best technology to produce top-of-the-line products.

The Threaded Brass Pipe Fittings are screwed fittings that have threads on their surface. This allows the fittings to be easily connected to subsequent pipes. These fittings are seen in applications where stress on the system is low. A Brass Coupling is a versatile fitting that creates a permanent connection between two pipes. These couplings can handle different stress and vibrations. Brass Union is similar to a coupling, but it can be disconnected in the future for maintenance or repair. The Brass Plug is utilized to seal the ends of threaded pipes to terminate the flow of media in oil and gas applications. Brass Nipples are a short piece of pipe having a male pipe thread ensuring a watertight sealing.

The Brass Compression Fittings are strong fittings that create a secure connection. These fittings are less appealing and are very bulky. A Brass Bulkhead Fitting allows for the fittings to allow for free flow of liquids and gases in tanks, drums and other connections. The Brass Flare Fittings are soft ductile compression fittings that are usually cold worked. They are seen in high-pressure and temperature applications. A Brass Ferrule is made with a circular clamp that allows it to connect different grades in treacherous conditions.

Leading stockist of Brass Buttweld Fittings , We can provide free sample of ASME SB62 Brass Stub End on demand

Why are Brass Fittings Used?

Why are Brass Fittings Used?

Brass Pipe Fittings Specification

Specifications ANSI Brass Fittings
Color Brass Yellow
Materials Brass,lead free brass
Standard JIS ANSI
Pressure Rating PN25
Temperature Rating -20°C upto 120°C
Sizes 7/8‘’, 1/2"

ASTM B62 Brass Fittings Price List

10-12% price difference if you buy directly from Brass Fittings manufacturers

Description Price Per Kg In Singapore Price Per Kg In UAE Price Per Kg In USD Price Per Kg In Malaysia
15MM 65 15MM 65 BRASS PIPE FITTINGS COMPRESSION RING SGD 22.21 UAE Dirham 58.00 US $16.04 MYR 70.34
254 MM SQUARE BRASS SANITARY FITTINGS SGD 27.68 UAE Dirham 72.29 US $19.99 MYR 87.67
1/8 BSPP-6MM BRASS COMPRESSION FITTING SGD 59.02 UAE Dirham 154.11 US $42.63 MYR 186.90
100X100X100 NB ALUMINIUM BRASS SEMI-FINISHED FITTINGS EQUAL TEE SEMI FINISHED SGD 35.96 UAE Dirham 93.91 US $25.97 MYR 113.89
3/4 X1/2 PIPE FITTING RED COUPLING BRASS THD SGD 0.54 UAE Dirham 1.41 US $0.39 MYR 1.71
1/4 FPT X 1/8 FPT BRASS FITTINGS RED COUPLING SGD 0.13 UAE Dirham 0.33 US $0.09 MYR 0.40

Brass Fittings Types

Brass Reducing Tee

Brass Reducing Tee

ASTM B62 Brass 45° Elbow

ASTM B62 Brass 45° Elbow

Brass Long Radius Elbow

Brass Long Radius Elbow

1/2 x 1/2 Brass Female Elbow

1/2 x 1/2 Brass Female Elbow

Brass Stub End

Brass Stub End

Forged Brass End Cap

Forged Brass End Cap

Brass Equal Cross

Brass Equal Cross

Industrial Brass 180° Elbow

Industrial Brass 180° Elbow

Brass Hex Nipple

Brass Hex Nipple

NPT Brass Plumbing Fittings

NPT Brass Plumbing Fittings

Brass Concentric Reducer

Brass Concentric Reducer

AS3688 Brass Short Radius Elbow

AS3688 Brass Short Radius Elbow

Brass 90° Elbow

Brass 90° Elbow

15mm X 15mm Brass Equal Tee

15mm X 15mm Brass Equal Tee

ASTM B62 Brass Eccentric Reducer

ASTM B62 Brass Eccentric Reducer

Industrial Brass Fitting Dimensions

More than 30 years experience as a Brass Pipe Fittings manufacturer in India

Industrial Brass Fitting Dimensions

Brass Reducing Forged Tees

Brass Reducing Forged Tees
A & B 1
NPT
3
NPT
2
NPT
Body Width Approx. Wt. Lbs.
0.72 1/8” 1/4” 1/8” 0.69 0.16
0.72 1/4” 1/8” 1/4” 0.69 0.14
0.81 1/4” 3/8” 1/4” 0.81 0.21
0.81 3/8” 3/8” 1/4” 0.81 0.18
0.81 3/8” 1/4” 3/8” 0.81 0.18
1.00 1/2” 3/8” 1/2” 1.00 0.30
1.20 3/4" 3/4" 1/2" 1.25 0.59
1.16 3/4” 1/2” 3/4” 1.25 0.59

ASTM B62 Brass Female Pipe x Female Pipe

Rishabh Steel is a industrial ASTM B62 Brass Fittings supplier in India since 2001, Quality Assurance, and Reliable Delivery globally

ASTM B62 Brass Female Pipe x Female Pipe
Hole Size A B Length (in.)
5/8 1/8-27 NPTF 5/8-18 UNS 0.96
5/8 1/8-27 NPTF 5/8-18 UNS 1-1/2
3/4 1/4-18 NPTF 3/4-16 UNS 15/16
3/4 1/4-18 NPTF 3/4-16 UNS 1-1/2
3/4 1/4-18 NPTF 3/4-16 UNS 1-1/2
1 3/8-18 NPTF 1-14 UNS 1-5/16
1-1/8 1/2-14 NPTF 1-1/8-14 UNS 1-1/2
1-5/16 3/4-14 NPTF 1-5/16-12 1-1/2
1-5/8 1-11/1/2 1-5/8-14 1.68

Brass Male Adapter

Brass Male Adapter
Approx. Wt. Lbs. Hose I.D. x Male NPTF Hex A B
0.04 1/4” x 1/8” 0.50 1.43 0.87
0.06 1/4” x 1/4” 0.56 1.66 0.87
0.06 1/4” x 3/8” 0.68 1.66 0.87
0.04 5/16” x 1/8” 0.43 1.42 0.77
0.06 5/16” x 1/4” 0.56 1.66 0.87
0.04 3/8” x 1/8” 0.50 1.53 0.97
0.07 3/8” x 1/4” 0.56 1.69 0.89
0.08 3/8” x 3/8” 0.68 1.76 0.97
0.10 3/8” x 1/2” 0.87 1.97 0.97
0.16 3/8” x 3/4” 1.06 1.97 0.92
0.08 1/2” x 1/4” 0.68 1.76 0.97
0.09 1/2” x 3/8” 0.68 1.76 0.97
0.14 1/2” x 1/2” 0.87 1.97 0.97
0.16 1/2” x 3/4” 1.06 1.97 0.97
0.12 5/8” x 3/8” 0.75 2.34 1.50
0.16 5/8” x 1/2” 0.87 2.45 1.45
0.18 5/8” x 3/4” 1.06 2.45 1.45
0.21 3/4” x 1/2” 0.87 2.45 1.45
0.20 3/4” x 3/4” 1.06 2.45 1.45
0.43 1” x 3/4” 1.25 2.93 1.50
0.49 1” x 1” 1.37 3.11 1.50

Ready stock of ASTM B62 UNS C36000 Equal/ Reducing Tee at reasonable cost, Brass Plug/ Union available in wider range of sizes

1/2 x 1/2 Brass 90° Female Elbow

1/2 x 1/2 Brass 90° Female Elbow
Thread Size NPTF B A Approx. Wt. Lbs.
1/8” 0.56 0.55 0.09
1/4” 0.68 0.78 0.13
3/8” 0.81 0.84 0.16
1/2” 1.00 1.09 0.34
3/4” 1.25 1.16 0.60

Brass Tee

We are a specialist supplier & distributor of Brass Compression Fittings and 1/2 x 1/2 Brass Pipe Fittings

Brass Tee
Approx. Wt. Lbs. Size A Body Size
0.04 1/8” 0.61 0.37
0.04 1/8” 0.62 0.33
0.08 3/16” 0.59 0.36
0.08 3/16” 0.60 0.38
0.10 1/4” 0.63 0.36
0.10 1/4” 0.62 0.49
0.13 5/16” 0.72 0.50
0.14 5/16” 0.60 0.50
0.16 3/8” 0.75 0.50
0.16 3/8” 0.73 0.59
0.22 1/2” 0.94 0.59
0.24 1/2” 0.94 0.69
0.28 5/8” 1.06 0.69
0.32 3/4” 1.22 0.88
0.34 7/8” 1.25 0.94

Chemical Composition of Brass Fitting

Brass Zn Fe Cu Pb
Min./Max. Rem. 0.35 60.0-63.0 2.5-3.0
Nominal 35.4 61.5 2.7

Brass Pipe Fittings Physical Properties

Properties US Customary
Melting Point -Solidus 1630 F
Modulas of Elasticity in Tension 14000 ksi
Melting Point -Liquidus 1650 F
Density 0.307 lb/in3at 68 F
Electrical Conductivity 26 %IACS @ 68 F
Electrical Resistivity 39.90 ohms – cmil/ft @ 68 F
Thermal Conductivity 67 Btu · ft/(hr · ft2·oF)at 68F

Industrial Brass Cross

Industrial Brass Cross
B th size NPTF A Approx. Wt. Lbs.
0.56 1/8” 0.55 0.10
0.68 1/4” 0.78 0.21
0.81 3/8” 0.84 0.25
1.00 1/2” 1.09 0.51
1.25 3/4” 1.16 0.75
Fast Delivery and cost-effective rates for ASME SB62 Brass Concentric/ Eccentric Reducer, Suppliers and Stockists of Threaded Brass Pipe Fittings

Brass Union

Why don't you directly contact a Forged Brass Threaded Fittings manufacturer in India? We offer an extensive range of Brass Plumbing Fitting and Brass Sanitary Fittings in Mumbai, free sample before dispatch of complete order.

Brass Union
Size Hex A Approx. Wt. Lbs.
1/8” 0.31 0.64 0.03
3/16” 0.37 0.75 0.04
1/4” 0.43 0.79 0.06
1/4” 0.43 0.81 0.06
5/16” 0.50 0.88 0.06
3/8” 0.56 0.96 0.09
3/8” 0.56 0.98 0.10
7/16” 0.62 1.02 0.12
1/2” 0.68 1.06 0.16
1/2” 0.68 1.25 0.16
5/8” 0.81 1.43 0.24
5/8” 0.81 1.25 0.26
3/4” 1.00 1.41 0.35
7/8” 1.12 1.03 0.34
7/8” 1.12 1.00 0.36

NPT Brass Female Pipe x Male Pipe

NPT Brass Female Pipe x Male Pipe
B A C Length (in.) Hole Size
1-14 UNS 1/4-18 NPTF 1/2-14 NPTF 29.43 2-1/8
1-14 UNS 3/8-18 NPTF 1/2-14 NPTF 15.46 1-11/16
1-14 UNS 3/8-18 NPTF 1/2-14 NPTF 15.40 1-29/32

AS3688 Brass 45° Female Elbow

AS3688 Brass 45° Female Elbow
Approx. Wt. Lbs. Thread size NPTF A B
0.06 1/8” 0.45 0.56
0.12 1/4” 0.66 0.68
0.16 3/8" 0.69 0.81
Biggest Brass Compression Fittings Distributor. Refer Dimensions and Sizes of UNS C36000 End Cap

Brass Female Adapter

Brass Female Adapter
Comp. X Female NPTF A Wt. Lbs. Hex
1/8” x 1/8” 0.75 0.02 0.56
3/16” x 1/8” 0.78 0.04 0.56
3/16” x 1/4” 0.96 0.04 0.68
1/4” x 1/8” 0.84 0.05 0.50
1/4” x 1/8” 0.78 0.05 0.56
1/4” x 1/4” 0.88 0.09 0.62
1/4” x 1/4” 1.03 0.09 0.68
1/4” x 1/2” 1.02 0.12 0.87
5/16” x 1/8” 0.81 0.05 0.56
5/16” x 1/4” 0.91 0.06 0.62
3/8” x 1/8” 0.88 0.06 0.56
3/8” x 1/4” 0.97 0.08 0.62
3/8” x 1/4” 1.06 0.08 0.68
3/8” x 3/8” 1.03 0.08 0.75
3/8” x 3/8” 1.06 0.10 0.81
3/8” x 1/2” 1.12 0.08 1.00
3/8” x 3/4” 1.19 0.14 1.16
1/2” x 1/4” 1.09 0.10 0.68
1/2” x 3/8” 0.94 0.12 0.81
1/2” x 3/8” 1.12 0.12 0.81
1/2” x 1/2” 1.19 0.12 1.00
1/2” x 1/2” 1.31 0.12 1.00
1/2” x 3/4” 1.25 0.18 1.16
5/8” x 1/2” 1.20 0.18 0.94
5/8” x 1/2” 1.38 0.18 1.00
5/8” x 3/4” 1.20 0.22 1.12
3/4” x 1/2” 1.25 0.26 1.06
3/4” x 3/4” 1.28 0.28 1.19
7/8” x 1/2” 1.28 0.32 1.19
7/8” x 3/4” 1.31 0.34 1.12

15mm X 15mm Brass Hex Nipple

Buy Brass Plumbing Fittings and Industrial Brass Fitting at wholesale price directly from manufacturers in India

15mm X 15mm Brass Hex Nipple
Hex Thread size NPTF Approx. Wt. Lbs. A
0.43 1/8” 0.02 0.91
0.43 1/8” 0.03 0.97
0.56 1/4” 0.04 1.12
0.56 1/4” 0.06 1.38
0.68 3/8” 0.07 1.25
0.68 3/8” 0.07 1.41
0.87 1/2” 0.11 1.50
0.87 1/2” 0.17 1.81
1.07 3/4" 0.17 1.55
1.13 3/4” 0.23 1.96
1.39 1" 0.22 1.75
1.37 1” 0.43 2.30

Brass Union Tee

Brass Union Tee
Approx. Wt. Lbs. Thread size NPTF B A C
0.08 1/8” 0.55 0.55 0.56
0.17 1/4” 0.78 0.78 0.68
0.22 3/8” 0.84 0.84 0.81
0.43 1/2” 1.09 1.09 1.00
0.64 3/4” 1.16 1.16 1.25
