Aluminum Fittings

Fittings can be defined as piping components that allow it to route the pipe to change the direction, branch connection, and join different pipes. The Aluminum Fittings are produced consisting of main alloys of ferrous, silicon, manganese, copper, zinc, and manganese. These fittings play an important role in regulating the flow of media in the system. Aluminum Tube Fittings help in the conveyance of fluids and gases in domestic, commercial, and industrial applications. The fittings are produced in different specifications and sizes to suit a wide spectrum of oil and gas applications. The Astm B361 are wrought aluminium alloys that are produced in socket weld or butt-weld welding procedures. The grade of aluminium fittings possess outstanding strength and showcase excellent mechanical properties. Aluminum Socket Weld Fittings are seen in smaller pipe diameters having a norminall diameter of NPS 2 or smaller. These fittings are fitted using a single fillet weld and are seen in applications where stress is low. The Aluminum Threaded Fittings is one of the oldest methods of joining different piping systems. These fittings are easy to fit and dismantle due to the threads present on their surface. We are the Aluminum Fittings manufacturers in India who have a stock of fittings of different schedules, sizes, and shapes that are suitable for different projects.

The Aluminum Tee is designed possessing one inlet with two outlets that are aligned at 90 degrees to the main connection line. Aluminum 90 Degree Elbow is employed to change the direction of fluid or gaseous media between two pipes at an angle of 90 degrees. These elbows are based on long or short specifications as the radius of curvature. The Aluminium Reducer helps in reducing the flow size from bigger to smaller pipes. They help in connecting pipes of dissimilar sizes efficiently. Aluminum Pipe End Caps are used to close the opening and the end of a pipe. They protect the piping grade during its movement and storage of the item. Aluminum Couplings are utilized to connect grades of the same diameters and are very useful if leakage is taken place in the system.

Why pay extra? Buying from Alloy 6061 Concentric/ Eccentric Reducer Stockist saves your cost, wide selection of Schedule 40/ 80 Aluminum Pipe Fittings in India

Aluminium Pipe Fittings Specification

10-12% price difference if you buy directly from Aluminum Pipe Fittings manufacturers

SIZE 1/8" upto 4"
PIPE FITTING END CONNECTION BUTT WELD, BARBED, THREADED, SOCKET WELD
THREAD METRIC, BSPP, NPT, BSPT, UNF
PRESSURE RATING 3000 PSI, 1500 PSI, 6000 PSI
PIPE FITTING PLATING SAND BLASTING, ANNODIZING
MATERIAL ALL GARDES OF ALUMINUM

ASTM B361 Aluminum Buttweld Pipe Fittings Price List

Aluminum Fittings Suppliers in India, we use only high quality & tested material to produce Aluminium Buttweld Fittings

Description Price Per Kg In Singapore Price Per Kg In UAE Price Per Kg In USD Price Per Kg In Malaysia
100 NB ALUMINIUM BRASS SEMI-FINISHED FITTING 90 DEG.SR ELBOW SEMI FINISHED SGD 34.36 UAE Dirham 89.72 US $24.82 MYR 108.81
125 X 100 X 125 NB ALUMINIUM BRASS SEMI-FINISHED FITTING UNEQUAL TEE SGD 40.09 UAE Dirham 104.67 US $28.95 MYR 126.94
16 x 16mm ALUMINIUM 6061 PIPE FITTING SGD 3.20 UAE Dirham 8.37 US $2.31 MYR 10.15

Aluminum Fittings Types

Aluminum Fittings

Aluminum Fittings

ASTM B361 Aluminum Lap Joint Stub Ends

ASTM B361 Aluminum Lap Joint Stub Ends

Aluminum Eccentric Reducer

Aluminum Eccentric Reducer

ASTM B361 Aluminum 6061 Elbow

ASTM B361 Aluminum 6061 Elbow

Aluminum 6061 Concentric Reducer

Aluminum 6061 Concentric Reducer

ASTM B241 Aluminum Laterals

ASTM B241 Aluminum Laterals

6061 Aluminum Stub End

6061 Aluminum Stub End

ASTM B361 Aluminum 6061 Cross Fitting

ASTM B361 Aluminum 6061 Cross Fitting

Aluminum 90 Degree Elbows

Aluminum 90 Degree Elbows

ASTM B361 Grade 6061 Equal Tee

ASTM B361 Grade 6061 Equal Tee

ASTM B361 Aluminum 180 Degree Elbows

ASTM B361 Aluminum 180 Degree Elbows

Aluminium Reducer

Aluminium Reducer

ASTM B241 Gr 6082 End Cap

ASTM B241 Gr 6082 End Cap

Aluminum Gr 6082 45 Degree Elbows

Aluminum Gr 6082 45 Degree Elbows

ASTM B241 Aluminum Reducing Tee

ASTM B241 Aluminum Reducing Tee

Aluminium Cross Tee

Aluminium Cross Tee

Aluminum 6061 Weld Elbows

Aluminum 6061 Weld Elbows

ASTM B241 Gr 6082 Return Bends

ASTM B241 Gr 6082 Return Bends

Pressure Rating for Aluminum 6061 Fitting

Temperature Ratings Pressure Class
150 300
1 1/4 - 2 Inches 1/4 - 1 Inches 2 1/2 - 3 Inches
(oC) (oF)
-29 to 66 -20 to 150 300 1500 2000 1000
93 200 265 1350 1785 910
121 250 225 1200 1575 825
149 300 185 1050 1360 735
177 350 150 900 1150 650
204 400 - 750 935 560
232 450 - 600 725 475
260 500 - 450 510 385
288 550 - 300 300 300

ASTM B241 Aluminum Tube Fittings Schedule Chart

Buttweld Fittings
DN Schedule 10S Schedule 40S
45° Elbow 90° Elbow Equal tee Stub end type (B) End cap 45° Elbow 90° Elbow Equal tee End cap Stub end type (B)
15 0.03 0.06 0.09 0.07 0.03 0.04 0.08 0.10 0.04 0.08
20 0.03 0.07 0.13 0.09 0.05 0.04 0.08 0.17 0.07 0.11
25 0.08 0.14 0.28 0.16 0.08 0.11 0.15 0.29 0.10 0.17
32 0.11 0.23 0.49 0.22 0.10 0.17 0.26 0.59 0.18 0.25
40 0.17 0.30 0.68 0.25 0.11 0.23 0.40 0.86 0.20 0.31
50 0.25 0.50 0.85 0.43 0.13 0.40 0.70 1.28 0.23 0.61
65 0.48 0.85 1.41 0.57 0.19 0.77 1.40 2.19 0.27 0.80
80 0.63 1.25 1.77 0.72 0.25 1.08 2.20 3.31 0.42 1.13
100 1.08 2.10 3.46 1.09 0.68 1.47 4.47 5.27 1.14 1.87
125 1.82 3.65 5.44 1.47 1.11 2.84 6.80 9.63 2.13 2.79
150 2.72 5.45 8.03 2.15 1.42 5.44 10.89 10.99 3.23 3.57
200 5.33 10.20 15.65 3.22 2.38 10.77 21.54 20.91 5.19 6.07
250 9.75 18.15 26.76 5.13 4.45 19.27 38.56 35.38 9.00 10.07
300 13.62 25.80 39.46 8.16 7.50 29.71 59.42 62.14 15.00 14.29
350 18.37 36.29 48.53 10.88 8.17 35.15 79.38 79.31 16.00 17.14
400 23.81 47.63 58.97 12.70 10.67 45.81 99.79 99.79 21.00 20.41
450 29.94 59.87 79.65 17.23 13.00 59.40 129.73 129.73 26.00 27.21
500 49.90 99.80 103.42 21.77 17.00 74.84 162.38 162.39 34.00 29.94
600 70.31 140.61 155.58 27.21 26.00 105.23 225.89 225.90 52.00 38.55

Contact directly a High Pressure Aluminum Pipe Fittings Exporter in India for lowest price and fast delivery, We keep Ready stock of Alloy 5083 Equal/ Reducing Tee

ASTM B361 Grade 6061 Elbow Weight Chart

Compare our quality and price with other Aluminum Elbows Suppliers in India

Elbow Pipe Fittings
PIPE NOMINAL SIZE OUTSIDE DIAM. 90° ELBOW 45° ELBOW 180° RETURNS
  Short Radius Long Radius Long Radius Long Radius
    Center to Face
(inches)
Center to Face
(inches)
Radius
(inches)
Center to Face
(inches)
Back to face
(inches)
Center to Center
(inches)
3/4 inches 26.7 mm 1.050 inches 1 1/8 7/16 1 11/16 2 1/4
1/2 inches 21.3 mm 0.840 inches 1 1/2 5/8 1 7/8 2
1 inches 33.4 mm 1.315 inches 1 1 1/2 7/8 2 3/16 3
1 1/2 inches 48.3 mm 1.900 inches 1 1/2 2 1/4 3 1 1/8 3 1/4 4 1/2
1 1/4 inches 42.2 mm 1.660 inches 1 1/4 1 7/8 1 2 3/4 3 3/4
2 inches 60.3 mm 2.375 inches 2 3 4 1 3/8 4 3/16 6
3 inches 88.9 mm 3.500 inches 3 4 1/2 6 2 6 1/4 9
2 1/2 inches 73.0 mm 2.875 inches 2 1/2 3 3/4 5 1 3/4 5 3/16 7 1/2
3 1/2 inches 101.6 mm 4.000 inches 3 1/2 5 1/4 7 2 1/4 7 1/4 10 1/2
5 inches 141.3 mm 5.563 inches 5 7 1/2 10 3 1/8 10 5/16 15
4 inches 114.3 mm 4.500 inches 4 6 8 2 1/2 8 1/4 12
6 inches 168.3 mm 6.625 inches 6 9 12 3 3/4 12 5/16 18
10 inches 273.1 mm 10.750 inches 10 15 15 6 1/4 20 3/8 30
8 inches 219.1 mm 8.625 inches 8 12 12 5 16 5/16 24
12 inches 323.9 mm 12.750 inches 12 18 18 7 1/2 24 3/8 36

Aluminum Weld Fitting Chemical Composition

Why don't you directly contact a MSS-SP-43 Aluminium Pipe Fittings manufacturer in India? We offer an extensive range of Aluminium Pipe Fittings and ASTM B361 Aluminum Fittings in Mumbai, free sample before dispatch of complete order.

Others Fe Ti Cu Mn Zn Mg Cr Si Al
0.15 max 0.70 max 0.15 max 0.15 - 0.40 0.15 max 0.25 max 0.8 - 1.2 0.04 - 0.35 0.40 - 0.80 Bal

ASTM B361 Aluminum Fittings Mechanical Properties

Melting Point Elongation Tensile Properties Density Yield Properties
582 °C 25 % Ksi – 45, MPa – 310 2.70 g/cm3 Ksi – 21, MPa – 145

6061 Aluminum Fittings Equivalent

UNS WERKSTOFF NR.
A96082 3.1254
Exporter of Aluminium 3003 End Cap and Threaded Aluminum Pipe Fittings supply with hydrostatic test pressure & MTR

ASTM B361 Aluminum 6061 Fittings Dimensions

Buy Aluminum Buttweld Pipe Fittings and Aluminum Butt Weld Fittings at wholesale price directly from manufacturers in India

Forms of Pipe Fttings Size Range Dimension Standards Schedules of Butt weld fittings
Seamless Pipe Fittings Welded Pipe Fittings
Elbows 1/8” NBt to 24" NB Upto 42" NB ANSI B16.9, ANSI B16.28, ASME B16.9, ASME B16.28, ANSI B16.25 Sch 5s, Sch 10, Sch 80s, Sch 100, Sch XXS, Sch 20, Sch 10s, Sch 40, Sch STD, Sch 40s, Sch 30, Sch XS, Sch 120, Sch 5, Sch 60, Sch 160, upto 50mm in case of welded fittings
Reducers 1/8” NB to 24" NB Upto 42" NB
Tees 1/8” NBt to 24" NB Upto 42" NB
End Caps 1/8” NBt to 24" NB Upto 42" NB
Swage Nipple 1/8” NB to 8" NB
Cross 1/8” NB to 8" NB
Return Bends 1/8” NB to 8" NB
Customized Pipe Fittings As Per Client Requirements

Size Chart of Aluminum Reducer

Reducer Fittings
DN Schedule 10S Schedule 40S
Ecc reducer Con reducer Reducing tee Con reducer Reducing tee Ecc reducer
400x300 18.35 18.35 51.71 36.70 87.54 36.70
25x15 0.12 0.12 0.25 0.15 0.26 0.15
20x15 0.10 0.10 0.11 0.14 0.15 0.14
25x20 0.13 0.13 0.25 0.16 0.27 0.16
32x25 0.18 0.18 0.45 0.22 0.53 0.22
32x20 0.18 0.18 0.44 0.22 0.52 0.22
40x20 0.18 0.18 0.58 0.24 0.74 0.24
40x32 0.24 0.21 0.61 0.28 0.77 0.28
40x25 0.19 0.19 0.60 0.26 0.76 0.26
50x25 0.28 0.28 0.73 0.40 1.10 0.40
50x40 0.31 0.31 0.76 0.45 1.15 0.45
50x32 0.30 0.30 0.74 0.44 1.13 0.44
65x40 0.44 0.44 1.24 0.76 1.94 0.76
80x40 0.51 0.51 1.52 0.94 2.85 0.94
65x50 0.47 0.47 1.25 0.80 1.98 0.80
80x50 0.55 0.55 1.56 1.00 2.91 1.00
100x40 0.68 0.68 2.90 1.36 4.53 1.36
80x65 0.59 0.59 1.59 1.08 2.98 1.08
100x50 0.78 0.78 2.94 1.57 4.48 1.57
100x80 0.87 0.87 3.04 1.74 4.64 1.74
100x65 0.83 0.83 2.97 1.66 4.54 1.66
125x100 1.49 1.49 5.49 2.98 8.47 2.98
150x100 1.96 1.96 7.10 4.07 9.68 4.07
150x80 1.82 1.82 6.86 3.98 11.94 3.98
150x125 2.00 2.00 7.27 4.07 9.99 4.07
200x150 3.19 3.19 14.08 6.94 18.82 6.94
250x100 4.73 4.73 22.75 10.52 30.07 10.52
200x100 3.01 3.01 13.46 6.55 17.98 6.55
250x150 5.00 5.00 23.55 11.12 31.13 11.12
300x200 7.67 7.67 34.73 15.98 54.43 15.98
250x200 5.20 5.20 24.08 11.56 31.84 11.56
300x250 7.98 7.98 35.52 16.63 55.79 16.63
400x200 16.70 16.70 49.90 33.40 84.82 33.40
350x300 15.29 15.29 43.96 30.58 71.21 30.58
400x250 17.22 17.22 50.80 35.43 85.73 35.43
Advanced NDT CRT Computed Radiographic Inspection for Aluminum Street/ Pulling Elbow and DIN 3.1255 Stub End

Aluminum Fittings Wall Thickness

O.D. (mm) Nominal Pipe Size W.T. (mm)
Sch 5S Sch 10S Sch 40S Sch 80S
NPS DN Weight (kg/m) WT (mm) Weight (kg/m) WT (mm) Weight (kg/m) WT (mm) Weight (kg/m) WT (mm)
10.3 6 0.28 1.24 0.37 1.73 0.47 2.41
13.7 ¼ 8 0.49 1.65 0.63 2.24 0.80 3.02
17.1 10 0.63 1.65 0.84 2.31 1.10 3.20
21.3 ½ 15 0.80 1.65 1.00 2.11 1.27 2.77 1.62 3.73
26.7 ¾ 20 1.02 1.65 1.28 2.11 1.69 2.87 2.20 3.91
33.4 1 25 1.29 1.65 2.09 2.77 2.50 3.38 3.24 4.55
42.2 32 1.65 1.65 2.69 2.77 3.39 3.56 4.47 4.85
48.3 40 1.90 1.65 3.11 2.77 4.05 3.68 5.41 5.08
60.3 2 50 2.39 1.65 3.93 2.77 5.44 3.91 7.48 5.54
73.0 65 3.69 2.11 5.26 3.05 8.63 5.16 11.41 7.01
88.9 3 80 4.52 2.11 6.46 3.05 11.29 5.49 15.27 7.62
101.6 90 5.18 2.11 7.41 3.05 13.57 5.74 18.64 8.08
114.3 4 100 5.84 2.11 8.37 3.05 16.08 6.02 22.32 8.56
141.3 5 125 9.46 2.77 11.56 3.40 21.77 6.55 30.97 9.53
168.3 6 150 11.31 2.77 13.83 3.40 28.26 7.11 42.56 10.97
219.1 8 200 14.78 2.77 19.97 3.76 42.55 8.18 64.64 12.70
273.1 10 250 22.61 3.40 27.79 4.19 60.31 9.27 81.56 12.70
323.9 12 300 31.25 3.96 35.99 4.57 73.88 9.53 97.47 12.70
355.6 14 350 34.34 3.96 41.36 4.78 81.33 9.53 107.40 12.70
406.4 16 400 41.56 4.19 47.34 4.78 93.27 9.53 123.31 12.70
457 18 450 46.79 4.19 53.31 4.78 105.17 9.53 139.16 12.70
508 20 500 59.32 4.78 68.65 5.54 117.15 9.53 155.13 12.70
559 22 550 65.33 4.78 75.62 5.54
610 24 600 82.58 5.54 94.53 6.35 141.12 9.53 187.07 12.70
660 26 650
711 28 700
762 30 750 118.34 6.35 147.29 7.92

ASTM B361 Aluminum Fittings Applications

The benefit of purchasing Aluminum Threaded Fittings and Aluminum Tee Fittings directly from manufacturers is the low cost and large selection of Anodized Aluminum Pipe Fittings which save your time

  • Heat Exchangers

  • Power Generation

  • Off-Shore Oil Drilling Companies

  • Chemical Equipment

  • Condensers

  • Petrochemicals

  • Pulp and Paper Industry

  • Pharmaceutical Equipment

  • Sea Water Equipment

  • Specialty Chemicals

  • Gas Processing

  • Pharmaceuticals
