Pipe fittings of the Hastelloy C22 grade impact the flow of media in the system. Hastelloy C22 Pipe Fittings are superalloy components that are produced with a unique chemical composition allowing them to possess good resistance to creep rupture and oxidation. The Hastelloy C22 Fittings are designed in different shapes and can be utilized in high-temperature conditions where mechanical stress is high. Alloy C22 Pipe Fittings have excellent metallurgical stability and are not sensitive to heating and welding processes. The nickel content in these fittings resists the formation of the grain boundary in the heat-affected zone. ASTM B366 UNS N06022 grade works well in aqueous media and is resistant to pitting by acids and crevice corrosion. The Alloy C22 Fittings have a density of 8.69 g/cm3 and possess a melting point of 1399 degrees C. These fittings possess a hardness of 89 HRB while showcasing good tensile and yield strength. The UNS N06022 Buttweld Fittings are quality-assured and available at the most reasonable prices across all our outlets.
The SB 366 UNS N06022 Elbow are pressure piping system that is used to change the direction of fluid or gaseous media. These elbows can connect piping equipmentof the same and different diameters. They are generally designed in long or short radius specifications. Alloy C22 SHort radius Elbow is a grade that possesses a radius of curvature that is equal to the outer diameter of the piping grade. The DIN 2.4602 Pipe bend is nearly similar to an elbow, but it has a radius of curvature which is larger than a standard elbow. A Hastelloy UNS N06022 Cap is used to cover the ends of piping grades. These caps protect these items against damage or corrosion. The Nickel Alloy C22 Stub End can be used as an alternative to a backing flange. These modules are designed with a short length of pipe that possess a flared end on one side with a square cut on the other. ASTM B366 N06022 Buttweld Reducer are high-strength adapters that are employed to connect piping equipment of dissimilar sizes.
Here are many benefits if you buy from hastelloy fittings suppliers, like high quality, best price and wide range of Hastelloy C22 Pipe Fittings
Specification | ASTM B366/ B564, ASME SB 366/ SB564 |
---|---|
Dimensions | ANSI/ASME B16.28, B16.9, MSS-SP-43 |
Size | 1/2″to 12″NB IN |
Thickness | Schedule 10 to Schedule XXS |
Types | Welded / ERW / Seamless / Fabricated |
Grades | Hastelloy B2 (UNS No. N10665), Hastelloy C22 (UNS No. N06022), Hastelloy C-4 (UNS No. N06455) |
Price of reseller is always higher compared to Hastelloy C22 Pipe Fittings manufacturers
Description | Price Per Kg In Singapore | Price Per Kg In UAE | Price Per Kg In USD | Price Per Kg In Malaysia |
---|---|---|---|---|
2.5 INCH X SCH 40 HASTELLOY PIPE FITTINGS ELBOW | SGD 177.17 | UAE Dirham 462.62 | US $127.96 | MYR 561.05 |
2.5 INCH 3000 PIPE FITTINGS COUPLING HALF COUPLING HASTELLOY C THREADED FITTINGS | SGD 373.27 | UAE Dirham 974.64 | US $269.58 | MYR 1,182.01 |
3INCH/SCH 40 HASTELLOY C-22 PIPE FITTINGS ALLOY C-22 FITTINGS | SGD 1,525.25 | UAE Dirham 3,982.59 | US $1,101.57 | MYR 4,829.95 |
4INCH/SCH 40 HASTELLOY B2 PIPE FITTINGS ALLOY B2 FITTINGS | SGD 2,180.63 | UAE Dirham 5,693.86 | US $1,574.90 | MYR 6,905.32 |
1/2 X SCH 10 HASTELLOY TEE FITTINGS | SGD 29.86 | UAE Dirham 77.97 | US $21.57 | MYR 94.56 |
1 X SCH 80 HASTELLOY B2 STUBEND FITTINGS | SGD 113.45 | UAE Dirham 296.24 | US $81.94 | MYR 359.27 |
3/4 X 3000# X 2 HASTELLOY C 22 FORGED FITTING HEX NIPPLE LONG THREADED FITTINGS | SGD 53.37 | UAE Dirham 139.36 | US $38.55 | MYR 169.01 |
Werkstoff No. 2.4617 Lap Joint Stub Ends
Hastelloy Reducing Tee
ASTM B564 Hastelloy Eccentric Reducer
Hastelloy ASTM B564 B2 Return Bends
Hastelloy C22 End Cap
Alloy C4 Elbow
Alloy C22 Weld Elbows
Hastelloy UNS N10665 Concentric Reducer
Hastelloy B2 45 Degree Elbows
C2000 Hastelloy Reducer
DIN 2.4602 90 Degree Elbows
Hastelloy Alloy Cross Tee
Hastelloy UNS N06455 Stub End
Hastelloy Pipe Fittings
ASME SB564M Hastelloy C22 Equal Tee
ASTM B564 Hastelloy 180 Degree Elbows
Hastelloy Laterals
Hastelloy C22 Cross Fitting
Alloy C22 Socket Weld Cross
Hastelloy Hexagon Plugs
Werkstoff No. 2.4617 Threaded Union
Hastelloy UNS N10665 Socket Weld Lateral Tee
ASTM B564 Hastelloy Threaded Bends
Hastelloy B2 Threaded Caps
Hastelloy ASTM B564 B2 Hexagon Bushing
ASME SB564M Hastelloy C22 Socket Weld Caps
C2000 Hastelloy Socket Weld Elbow
Hastelloy Alloy Square Plugs
Alloy C4 Threaded Tee
Hastelloy C22 Threaded Coupling
Hastelloy Socket Weld Tee
Hastelloy UNS N06455 Socket Weld Union
Hastelloy C22 Threaded Elbow
DIN 2.4602 Socket Weld Coupling
ASTM B564 Hastelloy Threaded Cross
Alloy C22 Lateral Outlets
ASTM B564 Hastelloy Socket Weld Outlets
Hastelloy B2 Threaded Outlets
Hastelloy ASTM B564 B2 Elbow Outlets
ASME SB564M Hastelloy C22 Welding Outlets
Hastelloy Alloy Swept Outlets
Hastelloy C22 Nipple Outlets
In-house manufacturing facilities to produce ASTM B366 UNS N06022 Material, manufacturer of Hastelloy Buttweld Fittings since 2001
Nominal size | OD | Elbows | Reducer | Caps | Returns | Stubs Ends | |||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Short | Long | Long | Short | Long | Short | Radius of fillet | Diam. of Lap | ||||||||
90 deg | 90 deg | 45 deg | |||||||||||||
DN | NPS | D | A | A | B | H | E | O | K | O | K | F | F | R | G |
20 | ¾ | 26.7 | 38 | 19 | 38 | 25 | 76 | 51 | 76 | 51 | 3 | 43 | |||
32 | 11/4 | 42.2 | 32 | 48 | 25 | 51 | 38 | 95 | 70 | 64 | 52 | 102 | 51 | 5 | 64 |
40 | 11/2 | 48.3 | 38 | 57 | 29 | 64 | 38 | 114 | 83 | 76 | 62 | 102 | 51 | 6 | 73 |
50 | 2 | 60.3 | 51 | 76 | 35 | 76 | 38 | 152 | 106 | 102 | 81 | 152 | 64 | 8 | 92 |
65 | 21/2 | 73.0 | 64 | 95 | 44 | 89 | 38 | 190 | 132 | 127 | 100 | 152 | 64 | 8 | 106 |
80 | 3 | 88.9 | 76 | 114 | 51 | 89 | 51 | 229 | 159 | 152 | 121 | 152 | 64 | 10 | 127 |
90 | 31/2 | 101.6 | 89 | 133 | 57 | 102 | 64 | 267 | 184 | 178 | 140 | 152 | 76 | 10 | 140 |
15 | ½ | 21.3 | 38 | 16 | 25 | 76 | 48 | 76 | 51 | 3 | 35 | ||||
100 | 4 | 114.3 | 102 | 152 | 64 | 102 | 64 | 305 | 210 | 203 | 159 | 152 | 76 | 11 | 157 |
200 | 8 | 219.1 | 203 | 305 | 127 | 152 | 102 | 610 | 414 | 406 | 313 | 203 | 102 | 13 | 270 |
250 | 10 | 273.0 | 254 | 381 | 159 | 178 | 127 | 762 | 518 | 508 | 391 | 254 | 127 | 13 | 324 |
300 | 12 | 323.8 | 305 | 457 | 190 | 203 | 152 | 914 | 619 | 610 | 467 | 254 | 152 | 13 | 381 |
350 | 14 | 355.6 | 356 | 533 | 222 | 330 | 165 | 1067 | 711 | 711 | 533 | 305 | 152 | 13 | 413 |
125 | 5 | 141.3 | 127 | 190 | 79 | 127 | 76 | 381 | 262 | 254 | 197 | 203 | 76 | 11 | 185 |
400 | 16 | 406.4 | 406 | 610 | 254 | 356 | 178 | 1219 | 813 | 813 | 610 | 305 | 152 | 13 | 470 |
25 | 1 | 33.4 | 25 | 38 | 22 | 51 | 38 | 76 | 56 | 51 | 41 | 102 | 51 | 3 | 51 |
450 | 18 | 457 | 457 | 686 | 286 | 381 | 203 | 1372 | 914 | 914 | 686 | 305 | 152 | 13 | 533 |
500 | 20 | 508 | 508 | 762 | 318 | 508 | 229 | 1524 | 1016 | 1016 | 762 | 305 | 152 | 13 | 584 |
1050 | 42 | 1067 | 1600 | 660 | 610 | 305 | |||||||||
550 | 22 | 559 | 559 | 838 | 343 | 508 | 254 | 1676 | 1118 | 1118 | 838 | 305 | 152 | 13 | 641 |
150 | 6 | 168.3 | 152 | 229 | 95 | 140 | 89 | 457 | 313 | 305 | 237 | 203 | 89 | 13 | 218 |
600 | 24 | 610 | 610 | 914 | 381 | 508 | 267 | 1829 | 1219 | 1219 | 914 | 305 | 152 | 13 | 692 |
650 | 26 | 660 | 991 | 405 | 610 | 267 | |||||||||
700 | 28 | 711 | 1067 | 438 | 610 | 267 | |||||||||
750 | 30 | 762 | 1143 | 470 | 610 | 267 | |||||||||
1100 | 44 | 1118 | 1676 | 695 | 610 | 343 | |||||||||
800 | 32 | 813 | 1219 | 502 | 610 | 267 | |||||||||
850 | 34 | 864 | 1295 | 533 | 610 | 267 | |||||||||
900 | 36 | 914 | 1372 | 565 | 610 | 267 | |||||||||
950 | 38 | 965 | 1448 | 600 | 610 | 305 | |||||||||
1200 | 48 | 1219 | 1829 | 759 | 711 | 343 | |||||||||
1000 | 40 | 1016 | 1524 | 632 | 610 | 305 | |||||||||
1150 | 46 | 1168 | 1753 | 727 | 711 | 343 |
Dimensions in mm | Nominal pipe size | Weight | Schedule | ||
---|---|---|---|---|---|
D | E | in.0 | kg/pce | t | |
609.06 | 266.07 | 24 | 34.0470 | 10s | 6.035 |
26.07 26.07 26.07 | 25.04 25.04 25.04 | 3/4 | 0.0050 0.0060 0.0060 | 10s 40s 80s | 2.011 2.087 3.091 |
21.03 21.03 21.03 | 25.04 25.04 25.04 | 1/2 | 0.0040 0.0050 0.0050 | 10s 40s 80s | 2.011 2.077 3.073 |
33.04 33.04 33.04 | 38.01 38.01 38.01 | 1 | 0.0090 0.0130 0.0130 | 10s 40s 80s | 2.077 3.038 4.055 |
48.03 48.03 48.03 | 38.01 38.01 38.01 | 1½ | 0.0140 0.0230 0.0240 | 10s 40s 80s | 2.077 3.068 5.008 |
42.02 42.02 42.02 | 38.01 38.01 38.01 | 1¼ | 0.0130 0.0170 0.0180 | 10s 40s 80s | 2.077 3.056 4.085 |
60.03 60.03 60.03 | 38.01 38.01 38.01 | 2 | 0.0170 0.0270 0.0340 | 10s 40s 80s | 2.077 3.091 5.054 |
88.09 88.09 88.09 | 50.08 50.08 50.08 | 3 | 0.0400 0.0710 0.0850 | 10s 40s 80s | 3.005 5.049 7.062 |
73.00 73.00 73.00 | 38.01 38.01 38.01 | 2½ | 0.0250 0.0450 0.0510 | 10s 40s 80s | 3.005 5.016 7.001 |
114.03 114.03 114.03 | 63.05 63.05 63.05 | 4 | 0.0650 1.0220 1.0610 | 10s 40s 80s | 3.005 6.002 8.056 |
168.03 168.03 168.03 | 88.09 88.09 88.09 | 6 | 1.0360 3.0230 4.0540 | 10s 40s 80s | 3.040 7.011 10.097 |
141.03 141.03 141.03 | 76.02 76.02 76.02 | 5 | 1.0020 1.0910 2.0550 | 10s 40s 80s | 3.040 6.055 9.053 |
219.01 219.01 | 101.06 101.06 | 8 | 2.0490 5.0670 | 10s 40s | 3.076 8.018 |
323.09 323.09 | 152.04 152.04 | 12 | 6.0530 13.0060 | 10s 40s | 4.057 9.053 |
273.01 273.01 | 127.00 127.00 | 10 | 4.0900 9.0210 | 10s 40s | 4.019 9.027 |
355.06 355.06 | 165.01 165.01 | 14 | 8.0160 15.0900 | 10s STD | 4.078 9.053 |
457.02 | 203.02 | 18 | 17.0960 | 10s | 4.078 |
406.04 406.04 | 177.08 177.08 | 16 | 14.0510 20.0000 | 10s STD | 4.078 9.053 |
508.00 | 228.06 | 20 | 27.0220 | 10s | 5.054 |
Length | Shank Dia. SD | Type | Socket | Laying Length A | Bore D | Wall Min. C | ||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SL | RL (Min) | Dia. B | Depth Min. K | |||||||||||
3000 | 6000 | |||||||||||||
3000 | 6000 | 3000 | 6000 | 3000 | 6000 | 6000 | 3000 | 3000 | 6000 | |||||
32 | 45 | 88.90 | 1 | 1 | 74.07 | 16 | 38 | 57 | 54.0 | 62.5 | 8.76 | |||
48 | 54 | 88.90 | 2 | 2 | 61.37 | 16 | 25 | 32 | 43.0 | 52.5 | 6.93 | |||
48 | 54 | 88.90 | 2 | 2 | 48.90 | 13 | 29 | 32 | 34.0 | 41.0 | 6.35 | |||
48 | 54 | 88.90 | 2 | 2 | 42.80 | 13 | 30 | 32 | 29.5 | 35.0 | 6.07 | |||
48 | 54 | 88.90 | 2 | 2 | 34.04 | 13 | 32 | 32 | 21.0 | 26.5 | 5.69 | |||
60 | 114.30 | 2 | 90.04 | 16 | 33 | 78.0 | 9.50 | |||||||
60 | 114.30 | 2 | 74.07 | 16 | 38 | 62.5 | 8.76 | |||||||
60 | 114.30 | 2 | 61.37 | 16 | 38 | 52.5 | 6.93 | |||||||
60 | 114.30 | 2 | 48.90 | 13 | 42 | 41.0 | 6.35 | |||||||
60 | 114.30 | 2 | 42.80 | 13 | 43 | 35.0 | 6.07 |
Dimensional Tolerance of Reducer Insert
Size | 1/4” 2-1/2” | Socket Diameter B | through through | 2” 3” | ± + | 0.25mm 0.40mm / -0.25mm |
---|---|---|---|---|---|---|
Size | 3/8” 1” 2-1/2” | Laying Length A | through through through | 3/4” 2” 4” | + + + | 1.50mm / -0.00mm 2.00mm / -0.00mm 2.50mm / -0.00mm |
Size | 1/4” 2-1/2” | Bore D | through through | 2” 3” | ± ± | 0.80mm 1.50mm |
Size | 3/8” 1” 2-1/2” | Shank Length SL | through through through | 3/4” 2” 4” | ± ± ± | 0.00mm / -1.50mm 0.00mm / -2.00mm 0.00mm / -2.50mm |
Size | 3/8” 2” 4” | Shank Diameter SD | through through | 1-1/2” 3” | ± ± ± | 0.25mm 0.50mm 0.75mm |
Buy Hastelloy Forged Fittings from trusted manufacturers, ADNOC certified supplier of Hastelloy C22 Fittings
DN | Schedule 10S | Schedule 40S | ||||||||
---|---|---|---|---|---|---|---|---|---|---|
45° Elbow | 90° Elbow | Equal tee | Stub end type (B) | End cap | 45° Elbow | 90° Elbow | Equal tee | End cap | Stub end type (B) | |
15 | 0.03 | 0.06 | 0.09 | 0.07 | 0.03 | 0.04 | 0.08 | 0.10 | 0.04 | 0.08 |
20 | 0.03 | 0.07 | 0.13 | 0.09 | 0.05 | 0.04 | 0.08 | 0.17 | 0.07 | 0.11 |
25 | 0.08 | 0.14 | 0.28 | 0.16 | 0.08 | 0.11 | 0.15 | 0.29 | 0.10 | 0.17 |
32 | 0.11 | 0.23 | 0.49 | 0.22 | 0.10 | 0.17 | 0.26 | 0.59 | 0.18 | 0.25 |
40 | 0.17 | 0.30 | 0.68 | 0.25 | 0.11 | 0.23 | 0.40 | 0.86 | 0.20 | 0.31 |
50 | 0.25 | 0.50 | 0.85 | 0.43 | 0.13 | 0.40 | 0.70 | 1.28 | 0.23 | 0.61 |
65 | 0.48 | 0.85 | 1.41 | 0.57 | 0.19 | 0.77 | 1.40 | 2.19 | 0.27 | 0.80 |
80 | 0.63 | 1.25 | 1.77 | 0.72 | 0.25 | 1.08 | 2.20 | 3.31 | 0.42 | 1.13 |
100 | 1.08 | 2.10 | 3.46 | 1.09 | 0.68 | 1.47 | 4.47 | 5.27 | 1.14 | 1.87 |
125 | 1.82 | 3.65 | 5.44 | 1.47 | 1.11 | 2.84 | 6.80 | 9.63 | 2.13 | 2.79 |
150 | 2.72 | 5.45 | 8.03 | 2.15 | 1.42 | 5.44 | 10.89 | 10.99 | 3.23 | 3.57 |
200 | 5.33 | 10.20 | 15.65 | 3.22 | 2.38 | 10.77 | 21.54 | 20.91 | 5.19 | 6.07 |
250 | 9.75 | 18.15 | 26.76 | 5.13 | 4.45 | 19.27 | 38.56 | 35.38 | 9.00 | 10.07 |
300 | 13.62 | 25.80 | 39.46 | 8.16 | 7.50 | 29.71 | 59.42 | 62.14 | 15.00 | 14.29 |
350 | 18.37 | 36.29 | 48.53 | 10.88 | 8.17 | 35.15 | 79.38 | 79.31 | 16.00 | 17.14 |
400 | 23.81 | 47.63 | 58.97 | 12.70 | 10.67 | 45.81 | 99.79 | 99.79 | 21.00 | 20.41 |
450 | 29.94 | 59.87 | 79.65 | 17.23 | 13.00 | 59.40 | 129.73 | 129.73 | 26.00 | 27.21 |
500 | 49.90 | 99.80 | 103.42 | 21.77 | 17.00 | 74.84 | 162.38 | 162.39 | 34.00 | 29.94 |
600 | 70.31 | 140.61 | 155.58 | 27.21 | 26.00 | 105.23 | 225.89 | 225.90 | 52.00 | 38.55 |
DENSITY (LB/IN 3) | 0.311 |
---|---|
MELTING POINT (°C) | 1351 – 1387 |
DENSITY (G/CM 3) | 8.61 |
MELTING POINT (°F) | 2464 – 2529 |
Body Wall Thickness G | DN | Depth of Socket Min. J | Center to Bottom of Socket-A | Socket Bore Dia. B | Bore Dia. Of Fitting D | Nom. Pipe Size | Socket Wall Thickness (2) C | ||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Class Designation | 90° Elbows Tees, Crosses | 45° Elbows | Class Designation | ||||||||||||||||||
6000 | 3000 | 9000 | Class Designation | Class Designation | Class Designation | 3000 | 6000 | 9000 | |||||||||||||
Min. | Min. | Min. | 6000 | 3000 | 9000 | 9000 | 3000 | 6000 | 3000 | 9000 | 6000 | Min | Ave. | Min | Ave. | Ave. | Min | ||||
3.15 | 2.41 | 6 | 9.5 | 11.0 | 11.0 | 8.0 | 8.0 | 10.8 | 6.9 | 4.0 | 1/8” | 3.18 | 3.18 | 3.43 | 3.96 | ||||||
3.68 | 3.02 | 8 | 9.5 | 13.5 | 11.0 | 8.0 | 8.0 | 14.2 | 9.3 | 6.4 | 1/4” | 3.30 | 3.78 | 4.01 | 4.60 | ||||||
4.01 | 3.20 | 10 | 9.5 | 15.5 | 13.5 | 8.0 | 11.0 | 17.6 | 12.6 | 9.2 | 3/8” | 3.50 | 4.01 | 4.37 | 5.03 | ||||||
4.78 | 3.73 | 7.47 | 15 | 9.5 | 19.0 | 15.5 | 25.5 | 15.5 | 11.0 | 12.5 | 21.8 | 15.8 | 6.4 | 11.8 | 1/2” | 4.09 | 4.67 | 5.18 | 5.97 | 9.35 | 8.18 |
5.56 | 3.91 | 7.82 | 20 | 12.5 | 22.5 | 19.0 | 28.5 | 19.0 | 13.0 | 14.0 | 27.2 | 21.0 | 11.1 | 15.6 | 3/4” | 4.27 | 4.90 | 6.04 | 6.96 | 9.78 | 8.56 |
6.35 | 4.55 | 9.09 | 25 | 12.5 | 27.0 | 22.5 | 32.0 | 20.5 | 14.0 | 17.5 | 33.9 | 26.7 | 15.2 | 20.7 | 1” | 4.98 | 5.69 | 6.93 | 7.92 | 11.38 | 9.96 |
6.35 | 4.85 | 9.70 | 32 | 12.5 | 32.0 | 27.0 | 35.0 | 22.5 | 17.5 | 20.5 | 42.7 | 35.1 | 22.8 | 29.5 | 1-1/4” | 5.28 | 6.07 | 6.93 | 7.92 | 12.14 | 10.62 |
7.14 | 5.08 | 10.15 | 40 | 12.5 | 38.0 | 32.0 | 38.0 | 25.5 | 20.5 | 25.5 | 48.8 | 40.9 | 28.0 | 34.0 | 1-1/2” | 5.54 | 6.35 | 7.80 | 8.92 | 12.70 | 11.12 |
8.74 | 5.54 | 11.07 | 50 | 16.0 | 41.0 | 38.0 | 54.0 | 28.5 | 25.5 | 28.5 | 61.2 | 52.5 | 38.2 | 42.9 | 2” | 6.04 | 6.93 | 9.50 | 10.92 | 13.84 | 12.12 |
7.01 | 65 | 16.0 | 41.0 | 28.5 | 73.9 | 62.7 | 2-1/2” | 7.67 | 8.76 | ||||||||||||
7.62 | 80 | 16.0 | 57.0 | 32.0 | 89.8 | 78.0 | 3” | 8.30 | 9.52 | ||||||||||||
8.56 | 100 | 19.0 | 66.5 | 41.0 | 115.2 | 102.3 | 4” | 9.35 | 10.69 |
P | S | Mn | C | Si | Co | Fe | Cr | Mo | Ni |
---|---|---|---|---|---|---|---|---|---|
0.02 max | 0.02 max | 0.50 max | 0.010 max | 0.08 max | 2.50 max | 2.00 – 6.00 | 20.00 – 22.50 | 12.50 – 14.50 | 50.015 min* |
Buy ASTM B564 UNS N06022 forged fittings and Hastelloy Butt Weld Fittings at competitive price directly from manufacturers
Melting Point (2550 °F) | Elongation | Tensile Properties | Density | (0.2%Offset) Yield Properties |
---|---|---|---|---|
1399 °C | 45 % | MPa – 690, Psi – 1,00,000 | 8.69 g/cm3 | MPa – 310, Psi – 45000 |
EN | WERKSTOFF NR. | UNS | JIS |
---|---|---|---|
NiCr21Mo14W | 2.4602 | N06022 | NW 6022 |
Pitting Resistance Test
Chemical Analysis – Spectro Analysis
Flattening Test
Micro and MacroTest
Hardness Test
Mechanical Testing Such as Tensile of Area
Intergranular Corrosion (IGC) Test
Chemical Equipment
Positive Material Identification – PMI Testing
DN | Schedule 10S | Schedule 40S | ||||
---|---|---|---|---|---|---|
Ecc reducer | Con reducer | Reducing tee | Con reducer | Reducing tee | Ecc reducer | |
400x300 | 18.35 | 18.35 | 51.71 | 36.70 | 87.54 | 36.70 |
25x15 | 0.12 | 0.12 | 0.25 | 0.15 | 0.26 | 0.15 |
20x15 | 0.10 | 0.10 | 0.11 | 0.14 | 0.15 | 0.14 |
25x20 | 0.13 | 0.13 | 0.25 | 0.16 | 0.27 | 0.16 |
32x25 | 0.18 | 0.18 | 0.45 | 0.22 | 0.53 | 0.22 |
32x20 | 0.18 | 0.18 | 0.44 | 0.22 | 0.52 | 0.22 |
40x20 | 0.18 | 0.18 | 0.58 | 0.24 | 0.74 | 0.24 |
40x32 | 0.24 | 0.21 | 0.61 | 0.28 | 0.77 | 0.28 |
40x25 | 0.19 | 0.19 | 0.60 | 0.26 | 0.76 | 0.26 |
50x25 | 0.28 | 0.28 | 0.73 | 0.40 | 1.10 | 0.40 |
50x40 | 0.31 | 0.31 | 0.76 | 0.45 | 1.15 | 0.45 |
50x32 | 0.30 | 0.30 | 0.74 | 0.44 | 1.13 | 0.44 |
65x40 | 0.44 | 0.44 | 1.24 | 0.76 | 1.94 | 0.76 |
80x40 | 0.51 | 0.51 | 1.52 | 0.94 | 2.85 | 0.94 |
65x50 | 0.47 | 0.47 | 1.25 | 0.80 | 1.98 | 0.80 |
80x50 | 0.55 | 0.55 | 1.56 | 1.00 | 2.91 | 1.00 |
100x40 | 0.68 | 0.68 | 2.90 | 1.36 | 4.53 | 1.36 |
80x65 | 0.59 | 0.59 | 1.59 | 1.08 | 2.98 | 1.08 |
100x50 | 0.78 | 0.78 | 2.94 | 1.57 | 4.48 | 1.57 |
100x80 | 0.87 | 0.87 | 3.04 | 1.74 | 4.64 | 1.74 |
100x65 | 0.83 | 0.83 | 2.97 | 1.66 | 4.54 | 1.66 |
125x100 | 1.49 | 1.49 | 5.49 | 2.98 | 8.47 | 2.98 |
150x100 | 1.96 | 1.96 | 7.10 | 4.07 | 9.68 | 4.07 |
150x80 | 1.82 | 1.82 | 6.86 | 3.98 | 11.94 | 3.98 |
150x125 | 2.00 | 2.00 | 7.27 | 4.07 | 9.99 | 4.07 |
200x150 | 3.19 | 3.19 | 14.08 | 6.94 | 18.82 | 6.94 |
250x100 | 4.73 | 4.73 | 22.75 | 10.52 | 30.07 | 10.52 |
200x100 | 3.01 | 3.01 | 13.46 | 6.55 | 17.98 | 6.55 |
250x150 | 5.00 | 5.00 | 23.55 | 11.12 | 31.13 | 11.12 |
300x200 | 7.67 | 7.67 | 34.73 | 15.98 | 54.43 | 15.98 |
250x200 | 5.20 | 5.20 | 24.08 | 11.56 | 31.84 | 11.56 |
300x250 | 7.98 | 7.98 | 35.52 | 16.63 | 55.79 | 16.63 |
400x200 | 16.70 | 16.70 | 49.90 | 33.40 | 84.82 | 33.40 |
350x300 | 15.29 | 15.29 | 43.96 | 30.58 | 71.21 | 30.58 |
400x250 | 17.22 | 17.22 | 50.80 | 35.43 | 85.73 | 35.43 |
W (Min) | F (Min) | E (Min) | Nominal Pipe Size | b | A (Min) | C (Min) | ||
---|---|---|---|---|---|---|---|---|
Inch | DN | 3000 | 6000 | |||||
26 | - | 10 | 1/8” | 6 | 5 | 2 | 11 | 6 |
36 | - | 15 | 1/4” | 8 | 8 | 6 | 15 | 6 |
31 | 10 | 15 | 1/4”x1/8” | 8 x 6 | 5 | 2 | 15 | 6 |
40 | - | 16 | 3/8” | 10 | 11 | 8 | 18 | 8 |
39 | 15 | 16 | 3/8”x1/4” | 10 x 8 | 8 | 6 | 18 | 8 |
48 | - | 20 | 1/2” | 15 | 14 | 11 | 22 | 8 |
44 | 16 | 20 | 1/2”x3/8” | 15 x 10 | 11 | 8 | 22 | 8 |
43 | 15 | 20 | 1/2”x1/4” | 15 x 8 | 8 | 6 | 22 | 8 |
52 | - | 21 | 3/4” | 20 | 19 | 13 | 27 | 10 |
50 | 20 | 21 | 3/4”x1/2” | 20 x 15 | 14 | 11 | 27 | 9 |
46 | 16 | 21 | 3/4”x3/8” | 20 x 10 | 11 | 8 | 27 | 9 |
60 | - | 25 | 1” | 25 | 24 | 17 | 35 | 10 |
56 | 21 | 25 | 1”x3/4” | 25 x 20 | 19 | 13 | 35 | 10 |
55 | 20 | 25 | 1”x1/2” | 25 x 15 | 14 | 11 | 35 | 10 |
68 | - | 26 | 1-1/2” | 40 | 38 | 30 | 50 | 16 |
67 | 25 | 26 | 1-1/2”x1” | 40 x 25 | 24 | 17 | 50 | 16 |
63 | 21 | 26 | 1-1/2”x3/4” | 40 x 20 | 19 | 13 | 50 | 16 |
62 | 20 | 26 | 1-1/2”x1/2” | 40 x 15 | 14 | 11 | 50 | 16 |
71 | - | 27 | 2” | 50 | 49 | 39 | 62 | 17 |
70 | 26 | 27 | 2”x1-1/2” | 50 x 40 | 38 | 30 | 62 | 17 |
70 | 25 | 27 | 2”x1” | 50 x 25 | 24 | 17 | 62 | 18 |
65 | 21 | 27 | 2”x3/4” | 50 x 20 | 19 | 13 | 62 | 17 |
65 | 20 | 27 | 2”x1/2” | 50 x 15 | 14 | 11 | 62 | 18 |
Threaded Fittings
Size Product | 3/4” | 1/4” | 1/8” | 3/8” | 1/2” | 1” | 2-1/2” | 1-1/2” | 3” | 1-1/4” | 2” | 4” | |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
90 Elbow | 2000 | 0.35 | 0.08 | 0.10 | 0.13 | 0.25 | 0.53 | 3.14 | 1.06 | 4.81 | 0.82 | 1.70 | 10.21 |
3000 | 0.69 | 0.14 | 0.10 | 0.29 | 0.43 | 1.14 | 5.99 | 2.63 | 8.88 | 1.42 | 2.92 | 14.85 | |
6000 | 1.31 | 0.33 | 0.17 | 0.45 | 0.80 | 1.61 | 9.88 | 3.79 | 17.73 | 2.93 | 7.31 | 15.76 | |
45 Elbow | 2000 | 0.27 | 0.08 | 0.09 | 0.10 | 0.20 | 0.41 | 3.46 | 0.82 | 5.44 | 0.68 | 1.41 | 8.96 |
3000 | 0.56 | 0.12 | 0.09 | 0.24 | 0.34 | 0.94 | 3.71 | 2.05 | 5.97 | 1.03 | 2.23 | 8.96 | |
6000 | 1.07 | 0.27 | 0.11 | 0.39 | 0.63 | 1.27 | 7.01 | 2.54 | 14.16 | 2.24 | 4.37 | 11.36 | |
Tee | 2000 | 0.43 | 0.12 | 0.13 | 0.17 | 0.31 | 0.69 | 4.11 | 1.39 | 6.12 | 1.07 | 2.16 | 14.74 |
3000 | 0.92 | 0.20 | 0.13 | 0.38 | 0.56 | 1.49 | 6.99 | 3.27 | 10.19 | 1.76 | 3.53 | 19.13 | |
6000 | 1.65 | 0.45 | 0.20 | 0.63 | 0.98 | 2.17 | 13.11 | 4.71 | 21.70 | 3.74 | 7.88 | 18.53 | |
Cross | 2000 | 0.54 | 0.14 | 0.17 | 0.21 | 0.39 | 0.83 | 5.26 | 1.75 | 7.58 | 1.26 | 2.65 | 16.35 |
3000 | 1.06 | 0.26 | 0.17 | 0.44 | 0.72 | 1.79 | 8.51 | 3.93 | 12.45 | 2.13 | 4.27 | 21.93 | |
Full Coupling | 3000 | 0.19 | 0.04 | 0.05 | 0.06 | 0.13 | 0.45 | 2.29 | 1.07 | 3.38 | 0.81 | 1.40 | 6.28 |
6000 | 0.50 | 0.13 | 0.08 | 0.20 | 0.34 | 0.87 | 4.20 | 1.94 | 6.10 | 1.09 | 2.87 | 10.04 | |
Half Coupling | 3000 | 0.10 | 0.02 | 0.02 | 0.03 | 0.06 | 0.23 | 1.13 | 0.54 | 1.68 | 0.34 | 0.70 | 3.11 |
Socket Weld Fittings
Size Product | 1-1/2” | 3/8” | 1/4” | 1/2” | 3” | 1” | 2-1/2” | 1/8” | 1-1/4” | 2” | 3/4” | 4” | |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
90 Elbow | 3000 | 1.08 | 0.12 | 0.08 | 0.22 | 5.38 | 0.53 | 3.20 | 0.09 | 0.84 | 1.68 | 0.33 | 10.95 |
6000 | 2.79 | 0.29 | 0.15 | 0.40 | 1.17 | 0.10 | 1.48 | 3.28 | 0.73 | ||||
45 Elbow | 3000 | 0.80 | 0.11 | 0.07 | 0.20 | 5.10 | 0.42 | 2.53 | 0.08 | 0.69 | 1.35 | 0.28 | 9.41 |
6000 | 2.01 | 0.26 | 0.14 | 0.36 | 0.92 | 0.09 | 1.11 | 2.09 | 0.57 | ||||
Tee | 3000 | 1.35 | 0.15 | 0.09 | 0.29 | 5.90 | 0.65 | 3.98 | 0.13 | 1.04 | 2.04 | 0.42 | 13.92 |
6000 | 3.37 | 0.43 | 0.20 | 0.56 | 1.49 | 0.14 | 1.93 | 3.95 | 0.94 | ||||
Cross | 3000 | 1.58 | 0.20 | 0.13 | 0.35 | 6.69 | 0.73 | 4.37 | 0.16 | 1.12 | 2.25 | 0.47 | 14.58 |
6000 | 3.96 | 0.45 | 0.26 | 0.67 | 1.75 | 0.17 | 2.26 | 4.42 | 1.07 | ||||
Full Coupling | 3000 | 0.59 | 0.07 | 0.05 | 0.13 | 1.78 | 0.29 | 1.40 | 0.04 | 0.45 | 0.86 | 0.17 | 2.85 |
6000 | 1.11 | 0.114 | 0.07 | 0.204 | 0.44 | 0.05 | 0.60 | 1.62 | 0.27 | ||||
Half Coupling | 3000 | 0.66 | 0.07 | 0.05 | 0.13 | 2.10 | 0.30 | 1.63 | 0.04 | 0.34 | 1.09 | 0.21 | 3.71 |
6000 | 1.25 | 0.12 | 0.09 | 0.21 | 0.51 | 0.06 | 0.75 | 1.92 | 0.31 | ||||
Red Coupling | 3000 | 0.59 | 0.07 | 0.05 | 0.13 | 1.88 | 0.27 | 1.42 | 0.04 | 0.49 | 0.97 | 0.19 | 3.31 |
6000 | 1.20 | 0.24 | 0.65 | 0.75 | 2.12 | 0.33 | |||||||
Cap | 3000 | 0.59 | 0.07 | 0.04 | 0.10 | 2.74 | 0.25 | 1.43 | 0.03 | 0.45 | 0.96 | 0.16 | 4.24 |
6000 | 0.94 | 0.10 | 0.08 | 0.16 | 0.36 | 0.05 | 0.64 | 1.41 | 0.23 | ||||
Union | 3000 | 1.61 | 0.25 | 0.28 | 0.35 | 5.15 | 0.81 | 3.50 | 0.28 | 1.10 | 2.16 | 0.49 | 11.59 |
The benefit of purchasing ASTM B366 UNS N06022 Pipe Fittings and Alloy C22 Socket weld Pipe Fittings directly from manufacturers is the low cost and large selection of ASTM B366 UNS N06022 Threaded Pipe Fittings which save your time
O.D. (mm) | Nominal Pipe Size | W.T. (mm) | ||||||||
---|---|---|---|---|---|---|---|---|---|---|
Sch 5S | Sch 10S | Sch 40S | Sch 80S | |||||||
NPS | DN | Weight (kg/m) | WT (mm) | Weight (kg/m) | WT (mm) | Weight (kg/m) | WT (mm) | Weight (kg/m) | WT (mm) | |
10.3 | ⅛ | 6 | 0.28 | 1.24 | 0.37 | 1.73 | 0.47 | 2.41 | ||
13.7 | ¼ | 8 | 0.49 | 1.65 | 0.63 | 2.24 | 0.80 | 3.02 | ||
17.1 | ⅜ | 10 | 0.63 | 1.65 | 0.84 | 2.31 | 1.10 | 3.20 | ||
21.3 | ½ | 15 | 0.80 | 1.65 | 1.00 | 2.11 | 1.27 | 2.77 | 1.62 | 3.73 |
26.7 | ¾ | 20 | 1.02 | 1.65 | 1.28 | 2.11 | 1.69 | 2.87 | 2.20 | 3.91 |
33.4 | 1 | 25 | 1.29 | 1.65 | 2.09 | 2.77 | 2.50 | 3.38 | 3.24 | 4.55 |
42.2 | 1¼ | 32 | 1.65 | 1.65 | 2.69 | 2.77 | 3.39 | 3.56 | 4.47 | 4.85 |
48.3 | 1½ | 40 | 1.90 | 1.65 | 3.11 | 2.77 | 4.05 | 3.68 | 5.41 | 5.08 |
60.3 | 2 | 50 | 2.39 | 1.65 | 3.93 | 2.77 | 5.44 | 3.91 | 7.48 | 5.54 |
73.0 | 2½ | 65 | 3.69 | 2.11 | 5.26 | 3.05 | 8.63 | 5.16 | 11.41 | 7.01 |
88.9 | 3 | 80 | 4.52 | 2.11 | 6.46 | 3.05 | 11.29 | 5.49 | 15.27 | 7.62 |
101.6 | 3½ | 90 | 5.18 | 2.11 | 7.41 | 3.05 | 13.57 | 5.74 | 18.64 | 8.08 |
114.3 | 4 | 100 | 5.84 | 2.11 | 8.37 | 3.05 | 16.08 | 6.02 | 22.32 | 8.56 |
141.3 | 5 | 125 | 9.46 | 2.77 | 11.56 | 3.40 | 21.77 | 6.55 | 30.97 | 9.53 |
168.3 | 6 | 150 | 11.31 | 2.77 | 13.83 | 3.40 | 28.26 | 7.11 | 42.56 | 10.97 |
219.1 | 8 | 200 | 14.78 | 2.77 | 19.97 | 3.76 | 42.55 | 8.18 | 64.64 | 12.70 |
273.1 | 10 | 250 | 22.61 | 3.40 | 27.79 | 4.19 | 60.31 | 9.27 | 81.56 | 12.70 |
323.9 | 12 | 300 | 31.25 | 3.96 | 35.99 | 4.57 | 73.88 | 9.53 | 97.47 | 12.70 |
355.6 | 14 | 350 | 34.34 | 3.96 | 41.36 | 4.78 | 81.33 | 9.53 | 107.40 | 12.70 |
406.4 | 16 | 400 | 41.56 | 4.19 | 47.34 | 4.78 | 93.27 | 9.53 | 123.31 | 12.70 |
457 | 18 | 450 | 46.79 | 4.19 | 53.31 | 4.78 | 105.17 | 9.53 | 139.16 | 12.70 |
508 | 20 | 500 | 59.32 | 4.78 | 68.65 | 5.54 | 117.15 | 9.53 | 155.13 | 12.70 |
559 | 22 | 550 | 65.33 | 4.78 | 75.62 | 5.54 | ||||
610 | 24 | 600 | 82.58 | 5.54 | 94.53 | 6.35 | 141.12 | 9.53 | 187.07 | 12.70 |
660 | 26 | 650 | ||||||||
711 | 28 | 700 | ||||||||
762 | 30 | 750 | 118.34 | 6.35 | 147.29 | 7.92 |
Temperature Ratings | Pressure Class | ||||
---|---|---|---|---|---|
150 | 300 | ||||
1 1/4 - 2 Inches | 1/4 - 1 Inches | 2 1/2 - 3 Inches | |||
(oC) | (oF) | ||||
-29 to 66 | -20 to 150 | 300 | 1500 | 2000 | 1000 |
93 | 200 | 265 | 1350 | 1785 | 910 |
121 | 250 | 225 | 1200 | 1575 | 825 |
149 | 300 | 185 | 1050 | 1360 | 735 |
177 | 350 | 150 | 900 | 1150 | 650 |
204 | 400 | - | 750 | 935 | 560 |
232 | 450 | - | 600 | 725 | 475 |
260 | 500 | - | 450 | 510 | 385 |
288 | 550 | - | 300 | 300 | 300 |
Center to End Elbow, Tee, Cross A | DN | Band O.D. H |
Center to End 45° Elbow C |
Minimum W.T. G |
Nom. Pipe Size | Thread Length Min. (1) | |||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
2000 | 3000 | 6000 | 2000 | 3000 | 6000 | 2000 | 3000 | 6000 | 2000 | 3000 | 6000 | B | L2 | ||
21 | 21 | 25 | 6 | 22 | 22 | 25 | 17 | 17 | 19 | 3.18 | 3.18 | 6.35 | 1/8” | 6.4 | 6.7 |
21 | 25 | 28 | 8 | 22 | 25 | 33 | 17 | 19 | 22 | 3.18 | 3.30 | 6.60 | 1/4” | 8.1 | 10.2 |
25 | 28 | 33 | 10 | 25 | 33 | 38 | 19 | 22 | 25 | 3.18 | 3.51 | 6.98 | 3/8” | 9.1 | 10.4 |
28 | 33 | 38 | 15 | 33 | 38 | 46 | 22 | 25 | 28 | 3.18 | 4.09 | 8.15 | 1/2” | 10.9 | 13.6 |
33 | 38 | 44 | 20 | 38 | 46 | 56 | 25 | 28 | 33 | 3.18 | 4.32 | 8.53 | 3/4” | 12.7 | 13.9 |
38 | 44 | 51 | 25 | 46 | 56 | 62 | 28 | 33 | 35 | 3.68 | 4.98 | 9.93 | 1” | 14.7 | 17.3 |
44 | 51 | 60 | 32 | 56 | 62 | 75 | 33 | 35 | 43 | 3.89 | 5.28 | 10.59 | 1-1/4” | 17.0 | 18.0 |
51 | 60 | 64 | 40 | 62 | 75 | 84 | 35 | 43 | 44 | 4.01 | 5.56 | 11.07 | 1-1/2” | 17.8 | 18.4 |
60 | 64 | 83 | 50 | 75 | 84 | 102 | 43 | 44 | 52 | 4.27 | 7.14 | 12.09 | 2” | 19.0 | 19.2 |
76 | 83 | 95 | 65 | 92 | 102 | 121 | 52 | 52 | 64 | 5.61 | 7.65 | 15.29 | 2-1/2” | 23.6 | 28.9 |
86 | 95 | 106 | 80 | 109 | 121 | 146 | 64 | 64 | 79 | 5.99 | 8.84 | 16.64 | 3” | 25.9 | 30.5 |
106 | 114 | 114 | 100 | 146 | 152 | 152 | 79 | 79 | 79 | 6.55 | 11.18 | 18.67 | 4” | 27.7 | 33.0 |
ASME B16.11 Hastelloy UNS N10665 Forged Fittings Dimensional Tolerance
Nominal diameter | ||||||
Item | Type of pipe Fitting | DN | 6 to 8 | 10 to 20 | 25 to 50 | 65 to 100 |
NPS | 1/8 to 1/4 | 3/8 to 3/4 | 1 to 2 | 2-1/2 to 4 | ||
Bore diameter of socket (B) | All types of Pipe Fitting | + 0.4 - 0 |
+ 0.5 - 0 |
|||
Bore diameter of fitting (D) | ± 0.7 | ± 1.4 | ||||
Concentricity of bore (X) | ± 0.8 | |||||
Coin cadence of axes (Y) | 1 / 200 Max | |||||
Center to bottom of socket (A) | 45, 90D Elbow, Tee, Cross | ± 1.0 | ± 1.5 | ± 2.0 | ± 2.5 | |
Bottom to bottom of socket (E) | Full Coupling | ± 1.5 | ± 3.0 | ± 4.0 | ± 5.0 | |
Bottom of socket to opposite face (F) | Half Coupling | ± 1.0 | ± 1.5 | ± 2.0 | ± 2.5 |
We are in top 10 supplier in these locations
Fadhili Gas Plant, Jubail, Saudi Arabia
RasGas RL(3) Common Offplot Projects Ras Laffan, Qatar
Sriracha Refinery Expansion-Thailand
Weatherford - Cielo Abu Dhabi
Adco Jebel Dhanna Crude Storage Tanks
Gorgon LNG Train 4-Australia
