We are leading MSS SP-75 Tee Fittings Manufacturer in India

MSS SP-75 Fittings

Fittings are adapters that help connect straight sections of piping equipment that allow it to regulate fluid and gaseous flow in the system. The MSS SP-75 Fittings are standard wrought butt-weld fittings that play a critical role to regulate or measure the flow. These fittings work well in high-pressure applications seen in oil, gas, transmission, and distribution systems. They are designed in either seamless or welded specifications. MSS Sp75 Seamless Fittings are produced using a standard extrusion process as billets are passed through steel to shape them. The absence of seams in these fittings gives them higher strength and better tolerances. The MSS SP-75 Welded Fittings are produced in long continuous lengths and are cheaper than seamless fittings. Produced by various bending welding methods, they have a more pressure capacity than standard seamless grade fittings. Generally, thin-walled piping equipment is preferred via welding production.

The MSS Sp 75 Elbow is one of the most common fittings that is used to change the direction of the flow between two piping grades. These elbows are available at angles of 45, 90 and 22.5 degree turns. MSS SP-75 Tee Fittings is a versatile fitting that is shaped in the form of a T. They have a single inlet with two outlets that are placed at 90 degrees to the main connection line. The MSS SP 75 End Cap is primarily used to close the ends of the hydraulic system. These caps are generally threaded, allowing them to be easily fitted and dissembled from the line. An MSS SP 75 Pipe Reducer helps join piping equipment of dissimilar sizes. These reducers ensure a smooth flow from a larger to a smaller reducing size pipe. They are designed in concentric and eccentric configurations.

Biggest Supplier of MSS Sp 75 Elbow and Pipe Reducer

MSS SP 75 WPHY Pipe Fittings Specification

Here are many benefits if you buy from MSS SP-75 Fittings Suppliers, like high quality, best price and wide range of MSS SP 75 Fittings

Specification MSS SP-75 Fittings
Coating Fitting Faces Anti-rust Paint, Cold and Hot Dip Galvanized, Oil Black Paint, Zinc Plated, Yellow Transparent
Rating Pressure 6000 LBS, 3000 LBS,9000 LBS
Sizes (SMLS UPTO 24”)
1/2” TO 36”
(Buttweld 8” TO 36” )
Fitting Machining Equipment Electric bevelling, Press, Bending, Pushing and, Sand-blasting machine
Standard ANSI B16.28, ANSI B16.9, JIS B2313, MSS-SP-43 Type b, MSS-SP-43 Type A, JIS B2312
Thickness Schedule 5S to Schedule 160
Class 3000#, 9000#, 2000#, 6000#

CS MSS SP 75 Weld Fittings Price List

Description Price Per Piece In Singapore Price Per Piece In UAE Price Per Piece In USD Price Per Piece In Malaysia
4 inch Alloy Steel Fittings ASTM A860 Wphy MSS SP-75 Lr 90 Degree Elbow SGD 1.38 UAE Dirham 3.67 US $ 1.00 MYR 4.39
1/2" NB X 48" ASTM A860 MSS SP 75 High Yield Carbon Steel Fittings SGD 55.13 UAE Dirham 146.92 US $ 40.00 MYR 175.80
5D ASTM A860 MSS SP-75 Pipe Fitting Bend Steel Carbon SGD 1.30 UAE Dirham 3.45 US $ 0.94 MYR 4.13
1/2" NB X 48" Buttweld ASTM A860 MSS SP 75 Pipe Fittings SGD 3.20 UAE Dirham 8.52 US $ 2.32 MYR 10.20
2 inch ASTM A860 MSS SP 75 Pipe Fitting SGD 3.02 UAE Dirham 11.02 US $ 2.19 MYR 9.63
3 inch Steel ASTM A860 MSS SP-75 Pipe Fittings SGD 1.34 UAE Dirham 3.56 US $ 0.97 MYR 4.26

MSS SP-75 Fittings Types

Save 10-12% if you buy directly from MSS SP-75 tee Fittings manufacturers

MSS SP 75 Laterals

MSS SP 75 Laterals

Carbon Steel MSS SP 75 Elbow

Carbon Steel MSS SP 75 Elbow

CS MSS SP 75 Cross Tee

CS MSS SP 75 Cross Tee

MSS SP-75 Reducing Tee

MSS SP-75 Reducing Tee

A860 MSS SP 75 180 Degree Elbows

A860 MSS SP 75 180 Degree Elbows

MSS SP-75 Stub End

MSS SP-75 Stub End

Carbon Steel MSS SP 75 Reducer

Carbon Steel MSS SP 75 Reducer

MSS SP-75 Weld Elbows

MSS SP-75 Weld Elbows

ANSI B16.9 MSS SP-75 Return Bends

ANSI B16.9 MSS SP-75 Return Bends

MSS SP-75 End Cap

MSS SP-75 End Cap

MSS SP 75 Eccentric Reducer

MSS SP 75 Eccentric Reducer

CS MSS SP 75 Lap Joint Stub Ends

CS MSS SP 75 Lap Joint Stub Ends

A860 MSS SP 75 45 Degree Elbows

A860 MSS SP 75 45 Degree Elbows

Carbon Steel MSS SP 75 Cross Fitting

Carbon Steel MSS SP 75 Cross Fitting

ANSI B16.9 MSS SP-75 90 Degree Elbows

ANSI B16.9 MSS SP-75 90 Degree Elbows

MSS SP-75 Fittings

MSS SP-75 Fittings

Carbon Steel MSS SP-75 Concentric Reducer

Carbon Steel MSS SP-75 Concentric Reducer

CS MSS SP 75 Equal Tee

CS MSS SP 75 Equal Tee

A860 MSS SP 75 Material Schedule Chart

Pipe Fittings
DN Schedule 10S Schedule 40S
45° Elbow 90° Elbow Equal tee Stub end type (B) End cap 45° Elbow 90° Elbow Equal tee End cap Stub end type (B)
15 0.03 0.06 0.09 0.07 0.03 0.04 0.08 0.10 0.04 0.08
20 0.03 0.07 0.13 0.09 0.05 0.04 0.08 0.17 0.07 0.11
25 0.08 0.14 0.28 0.16 0.08 0.11 0.15 0.29 0.10 0.17
32 0.11 0.23 0.49 0.22 0.10 0.17 0.26 0.59 0.18 0.25
40 0.17 0.30 0.68 0.25 0.11 0.23 0.40 0.86 0.20 0.31
50 0.25 0.50 0.85 0.43 0.13 0.40 0.70 1.28 0.23 0.61
65 0.48 0.85 1.41 0.57 0.19 0.77 1.40 2.19 0.27 0.80
80 0.63 1.25 1.77 0.72 0.25 1.08 2.20 3.31 0.42 1.13
100 1.08 2.10 3.46 1.09 0.68 1.47 4.47 5.27 1.14 1.87
125 1.82 3.65 5.44 1.47 1.11 2.84 6.80 9.63 2.13 2.79
150 2.72 5.45 8.03 2.15 1.42 5.44 10.89 10.99 3.23 3.57
200 5.33 10.20 15.65 3.22 2.38 10.77 21.54 20.91 5.19 6.07
250 9.75 18.15 26.76 5.13 4.45 19.27 38.56 35.38 9.00 10.07
300 13.62 25.80 39.46 8.16 7.50 29.71 59.42 62.14 15.00 14.29
350 18.37 36.29 48.53 10.88 8.17 35.15 79.38 79.31 16.00 17.14
400 23.81 47.63 58.97 12.70 10.67 45.81 99.79 99.79 21.00 20.41
450 29.94 59.87 79.65 17.23 13.00 59.40 129.73 129.73 26.00 27.21
500 49.90 99.80 103.42 21.77 17.00 74.84 162.38 162.39 34.00 29.94
600 70.31 140.61 155.58 27.21 26.00 105.23 225.89 225.90 52.00 38.55

CS MSS SP 75 Elbow Sizes

ASTM A860 MSS SP-75 materials manufacturer in India offers Free Sample and Bulk Discounts

Elbow Pipe Fittings
45°
Long Radius
Center to End
B
90°
Long Radius
Center to End
A
NPS 45°
3D
Center to End
B
90°
3D
Center to End
A
O.D.
D
57 133 3.1/2 111 267 101.6
64 152 4 127 305 114.3
79 190 5 157 381 141.3
95 229 6 189 457 168.3
127 305 8 252 610 219.1
16 38 1/2 21.3
19 38 3/4 24 57 26.7
22 38 1 31 76 33.4
25 48 1.1/4 39 95 42.2
29 57 1.1/2 47 114 48.3
35 76 2 63 152 60.3
44 95 2.1/2 79 190 73
51 114 3 95 229 88.9
159 381 10 316 762 273
190 457 12 378 914 323.8
222 533 14 441 1067 355.6
254 610 16 505 1219 406.4

Weight Chart of MSS SP-75 Reducer

Reducer Fittings
DN Schedule 10S Schedule 40S
Ecc reducer Con reducer Reducing tee Con reducer Reducing tee Ecc reducer
400x300 18.35 18.35 51.71 36.70 87.54 36.70
25x15 0.12 0.12 0.25 0.15 0.26 0.15
20x15 0.10 0.10 0.11 0.14 0.15 0.14
25x20 0.13 0.13 0.25 0.16 0.27 0.16
32x25 0.18 0.18 0.45 0.22 0.53 0.22
32x20 0.18 0.18 0.44 0.22 0.52 0.22
40x20 0.18 0.18 0.58 0.24 0.74 0.24
40x32 0.24 0.21 0.61 0.28 0.77 0.28
40x25 0.19 0.19 0.60 0.26 0.76 0.26
50x25 0.28 0.28 0.73 0.40 1.10 0.40
50x40 0.31 0.31 0.76 0.45 1.15 0.45
50x32 0.30 0.30 0.74 0.44 1.13 0.44
65x40 0.44 0.44 1.24 0.76 1.94 0.76
80x40 0.51 0.51 1.52 0.94 2.85 0.94
65x50 0.47 0.47 1.25 0.80 1.98 0.80
80x50 0.55 0.55 1.56 1.00 2.91 1.00
100x40 0.68 0.68 2.90 1.36 4.53 1.36
80x65 0.59 0.59 1.59 1.08 2.98 1.08
100x50 0.78 0.78 2.94 1.57 4.48 1.57
100x80 0.87 0.87 3.04 1.74 4.64 1.74
100x65 0.83 0.83 2.97 1.66 4.54 1.66
125x100 1.49 1.49 5.49 2.98 8.47 2.98
150x100 1.96 1.96 7.10 4.07 9.68 4.07
150x80 1.82 1.82 6.86 3.98 11.94 3.98
150x125 2.00 2.00 7.27 4.07 9.99 4.07
200x150 3.19 3.19 14.08 6.94 18.82 6.94
250x100 4.73 4.73 22.75 10.52 30.07 10.52
200x100 3.01 3.01 13.46 6.55 17.98 6.55
250x150 5.00 5.00 23.55 11.12 31.13 11.12
300x200 7.67 7.67 34.73 15.98 54.43 15.98
250x200 5.20 5.20 24.08 11.56 31.84 11.56
300x250 7.98 7.98 35.52 16.63 55.79 16.63
400x200 16.70 16.70 49.90 33.40 84.82 33.40
350x300 15.29 15.29 43.96 30.58 71.21 30.58
400x250 17.22 17.22 50.80 35.43 85.73 35.43

View Price list and Sizes of MSS Sp75 Seamless Fittings and MSS SP 75 End Cap

MSS SP-75 Buttweld Pipe Fittings Chemical Composition

Elements Value, %
Manganese (Mn) ≤1.60
Carbon (C) ≤0.30
Phosphorus (P) ≤0.035
Copper (Cu) ≤0.50
Sulfur (S) ≤0.035
Nickel (Ni) ≤0.50
Chromium (Cr) ≤0.25
Silicon (Si) ≤0.50
Molybdenum (Mo) ≤0.13
Columbium (Cb) ≤0.10
Vanadium (V) ≤0.13
Titanium(Ti) ≤0.05

Carbon Steel MSS SP 75 Pipe Fittings Mechanical Properties

MSS SP 75 Class Charpy Test Tensile Properties Yield Properties Elongation
Ave. Energy absorbed @ 20°F Min. psi Min. psi min. %
WPHY-42 ≥20ft*lbs 60000 42000 25
WPHY-46 63000 46000 25
WPHY-52 66000 52000 25
WPHY-56 71000 56000 20
WPHY-60 75000 60000 20
WPHY-65 77000 65000 20
WPHY-70 82000 70000 18
One of the leading MSS SP-75 Fittings manufacturer in India, Check Dimensions of MSS Sp75 Stub End

MSS SP-75 Fittings Applications

Why don't you directly contact a MSS SP-75 Elbow Fittings suppliers? Extensive range and lowest price for MSS SP-75 Fittings Manufacturers in India

  • Petrochemical Industries

  • Gas Processing Industries

  • Food Processing Industries

  • Power Generation Industries

  • Chemical Industries

  • Sugar Industries

  • Fertilizers Industries

  • Oil & Gas Industries

Carbon Steel MSS SP 75 Fittings Wall Thickness

O.D. (mm) Nominal Pipe Size W.T. (mm)
Sch 5S Sch 10S Sch 40S Sch 80S
NPS DN Weight (kg/m) WT (mm) Weight (kg/m) WT (mm) Weight (kg/m) WT (mm) Weight (kg/m) WT (mm)
10.3 6 0.28 1.24 0.37 1.73 0.47 2.41
13.7 ¼ 8 0.49 1.65 0.63 2.24 0.80 3.02
17.1 10 0.63 1.65 0.84 2.31 1.10 3.20
21.3 ½ 15 0.80 1.65 1.00 2.11 1.27 2.77 1.62 3.73
26.7 ¾ 20 1.02 1.65 1.28 2.11 1.69 2.87 2.20 3.91
33.4 1 25 1.29 1.65 2.09 2.77 2.50 3.38 3.24 4.55
42.2 32 1.65 1.65 2.69 2.77 3.39 3.56 4.47 4.85
48.3 40 1.90 1.65 3.11 2.77 4.05 3.68 5.41 5.08
60.3 2 50 2.39 1.65 3.93 2.77 5.44 3.91 7.48 5.54
73.0 65 3.69 2.11 5.26 3.05 8.63 5.16 11.41 7.01
88.9 3 80 4.52 2.11 6.46 3.05 11.29 5.49 15.27 7.62
101.6 90 5.18 2.11 7.41 3.05 13.57 5.74 18.64 8.08
114.3 4 100 5.84 2.11 8.37 3.05 16.08 6.02 22.32 8.56
141.3 5 125 9.46 2.77 11.56 3.40 21.77 6.55 30.97 9.53
168.3 6 150 11.31 2.77 13.83 3.40 28.26 7.11 42.56 10.97
219.1 8 200 14.78 2.77 19.97 3.76 42.55 8.18 64.64 12.70
273.1 10 250 22.61 3.40 27.79 4.19 60.31 9.27 81.56 12.70
323.9 12 300 31.25 3.96 35.99 4.57 73.88 9.53 97.47 12.70
355.6 14 350 34.34 3.96 41.36 4.78 81.33 9.53 107.40 12.70
406.4 16 400 41.56 4.19 47.34 4.78 93.27 9.53 123.31 12.70
457 18 450 46.79 4.19 53.31 4.78 105.17 9.53 139.16 12.70
508 20 500 59.32 4.78 68.65 5.54 117.15 9.53 155.13 12.70
559 22 550 65.33 4.78 75.62 5.54
610 24 600 82.58 5.54 94.53 6.35 141.12 9.53 187.07 12.70
660 26 650
711 28 700
762 30 750 118.34 6.35 147.29 7.92

ANSI B16.9 MSS SP-75 Pipe Fittings Dimensions

Pipe Fittings
Nominal size OD Elbows Reducer Caps Returns Stubs Ends
Short Long Long Short Long Short Radius of fillet Diam. of Lap
90 deg 90 deg 45 deg
DN NPS D A A B H E O K O K F F R G
20 ¾ 26.7 38 19 38 25 76 51 76 51 3 43
32 11/4 42.2 32 48 25 51 38 95 70 64 52 102 51 5 64
40 11/2 48.3 38 57 29 64 38 114 83 76 62 102 51 6 73
50 2 60.3 51 76 35 76 38 152 106 102 81 152 64 8 92
65 21/2 73.0 64 95 44 89 38 190 132 127 100 152 64 8 106
80 3 88.9 76 114 51 89 51 229 159 152 121 152 64 10 127
90 31/2 101.6 89 133 57 102 64 267 184 178 140 152 76 10 140
15 ½ 21.3 38 16 25 76 48 76 51 3 35
100 4 114.3 102 152 64 102 64 305 210 203 159 152 76 11 157
200 8 219.1 203 305 127 152 102 610 414 406 313 203 102 13 270
250 10 273.0 254 381 159 178 127 762 518 508 391 254 127 13 324
300 12 323.8 305 457 190 203 152 914 619 610 467 254 152 13 381
350 14 355.6 356 533 222 330 165 1067 711 711 533 305 152 13 413
125 5 141.3 127 190 79 127 76 381 262 254 197 203 76 11 185
400 16 406.4 406 610 254 356 178 1219 813 813 610 305 152 13 470
25 1 33.4 25 38 22 51 38 76 56 51 41 102 51 3 51
450 18 457 457 686 286 381 203 1372 914 914 686 305 152 13 533
500 20 508 508 762 318 508 229 1524 1016 1016 762 305 152 13 584
1050 42 1067 1600 660 610 305
550 22 559 559 838 343 508 254 1676 1118 1118 838 305 152 13 641
150 6 168.3 152 229 95 140 89 457 313 305 237 203 89 13 218
600 24 610 610 914 381 508 267 1829 1219 1219 914 305 152 13 692
650 26 660 991 405 610 267
700 28 711 1067 438 610 267
750 30 762 1143 470 610 267
1100 44 1118 1676 695 610 343
800 32 813 1219 502 610 267
850 34 864 1295 533 610 267
900 36 914 1372 565 610 267
950 38 965 1448 600 610 305
1200 48 1219 1829 759 711 343
1000 40 1016 1524 632 610 305
1150 46 1168 1753 727 711 343

MSS SP-75 Fittings Pressure Rating

The benefit of purchasing MSS SP-75 Buttweld Pipe Fittings and aaaaaaaa directly from manufacturers is the reduced cost and wide selection which save your time

W.T.
(in) (mm)
Pipe SCH Pipe Size
(inches)
Temperature (oF) (deg C) O.D.
(in) (mm)
100 200 300 400 500 600 650 700 750
Allowable Stress (psi) (kPa)
16700 16700 16700 15500 14400 13500 13200 12900 12600
0.145 40 1 1/2" 1629 1629 1629 1512 1404 1317 1287 1258 1229 1.900
0.200 80 2303 2303 2303 2138 1986 1862 1821 1779 1738 1.900
0.281 160 3362 3362 3362 3120 2899 2717 2657 2597 2536 1.900
0.133 40 1" 2205 2205 2205 2047 1902 1783 1743 1703 1664 1.315
0.179 80 3061 3061 3061 2841 2640 2475 2420 2365 2310 1.315
0.250 160 4493 4493 4493 4170 3874 3632 3552 3471 3390 1.315
0.154 40 2" 1371 1371 1371 1272 1182 1108 1083 1059 1034 2.375
0.218 80 1985 1985 1985 1843 1712 1605 1569 1534 1498 2.375
0.344 160 3283 3283 3283 3047 2831 2654 2595 2536 2477 2.375
0.237 40 4" 1102 1102 1102 1023 950 891 871 851 831 4.500
0.337 80 1596 1596 1596 1482 1377 1291 1262 1233 1204 4.500
0.531 160 2611 2611 2611 2424 2552 2111 2064 2017 1970 4.500
0.216 40 3" 1301 1301 1301 1208 1122 1052 1028 1005 982 3.500
0.300 80 1844 1844 1844 1712 1590 1491 1458 1425 1391 3.500
0.438 160 2787 2787 2787 2587 2403 2253 2203 2153 2103 3.500
0.258 40 5" 965 965 965 896 832 780 763 746 728 5.563
0.375 80 1428 1428 1428 1325 1231 1154 1129 1103 1077 5.563
0.625 160 2474 2474 2474 2296 2133 2000 1955 1911 1866 5.563
0.322 40 8" 771 771 771 716 665 623 610 596 582 8.625
0.500 80 1218 1218 1218 1131 1050 985 963 941 919 8.625
0.906 160 2298 2298 2298 2133 1982 1858 1817 1775 1734 8.625
0.280 40 6" 877 877 877 814 756 709 693 677 661 6.625
0.432 80 1379 1379 1379 1280 1189 1115 1090 1065 1040 6.625
0.719 160 2382 2382 2382 2211 2054 1925 1883 1840 1797 6.625
0.365 40 10" 699 699 699 649 603 565 553 540 528 10.750
0.594 80 1159 1159 1159 1075 999 937 916 895 874 10.750
1.125 160 2289 2289 2289 2124 1974 1850 1809 1768 1727 10.750
Leading Stockist and Exporter of MSS SP-75 Welded Fittings

Know which material supplied where

Union Carbide And Petronas Petrochemical Facility - Engineering Malaysia

Union Carbide And Petronas Petrochemical Facility - Engineering Malaysia

Al Sunaynah Dairy Processing Plant Project Oman, Azaibah

Al Sunaynah Dairy Processing Plant Project Oman, Azaibah

Doha South Sewage Treatment Works-Qatar

Doha South Sewage Treatment Works-Qatar

Markmore Energy (Labuan) Ltd-Malaysia

Markmore Energy (Labuan) Ltd-Malaysia

Petrovietnam Vietnam

Petrovietnam Vietnam

Brunei Darussalam-Thailand

Brunei Darussalam-Thailand
