Copper Fittings Manufacturers in India

Fittings are used to connect piping grades of different sizes allowing them to influence the characteristics of the flow in the system. The Copper Pipe Fittings have a higher content of carbon than other constituents. These fittings have good strength and have enhanced corrosion resistance properties. The Copper Elbow Fitting is installed between two lengths of a piping grade. These fittings help change the direction of fluid and gaseous media. They are generally available in 45 and 90-degree types. Copper 90 Degree Elbow is one of the common types of elbows that allow for a smooth flow of media. These elbows are divided into long or short radius configurations based on their radius of curvature. The Copper Tee is produced in the shape of a T and can combine or divide the flow of media. These tees are specified in equal and unequal sizes across the three channels. Copper Tee Fitting can transport two-fluid mixtures at an angle of 90 degrees while the main connection line supplies the media. These fittings are available in different sizes as per requirements. A Copper U Bend allows for a 180-degree return of media. This bend allows for creating a barrier against any foul smell in the oil and gas industries. The Copper Pipe End Cap helps in cutting the flow in the ends of the pipeline. These caps help in protecting the grade against damage or corrosive affluents when it is transported or stored. A Copper Reducer is used to join piping components of dissimilar sizes. The reducer is availed in concentric and eccentric types. Our institution is Copper Fittings manufacturers in India who follow all international and national standards while producing the best products in the industry.

The Threaded Copper Fittings have threads that are screwed and can be easily connected to subsequent piping grades having threads. Threaded Copper Fittings are easy to assemble without requiring any welding operation. These fittings are generally seen in low-pressure and temperature setups. Copper Compression Fittings are lock-bush fittings that possess a tapered, conical seat that is fastened by a hollow barrel-shaped ring-type compression that is fastened with a nut. The Copper Pipe Coupling is utilized in connecting pipes of the same diameters. These couplings are designated in regular and slip coupling. Copper Coupling can tolerate slight misalignment and can tolerate shocks and vibrations.

Exporter of Cu Concentric/ Eccentric Reducer and Threaded Copper Fittings supply with stamping, marking, & Pre-shipment Inspection

Copper Fittings Specification

Specifications ASTM/ ASME B62 / SB62
End Welding, Threaded, JIC
Types DN15 upto DN1200
Pressure rating 3000 LBS, 9000 LBS, 2000 LBS, 6000 LBS
Test Certificates EN 10204/3.1B
Raw Materials Certificate
100% Radiography Test Report
Third Party Inspection Report, etc
Connection Welding
copper fittings manufacturers in India
  • Cu. Pipe Fitting make Ulma, Spain
  • Cu. Alloy Pipe Fitting make TecnoForge, Italy
  • Cu. Alloy Pipe Fitting make BENKAN Corporation, Japan
  • Cu. Pipe Fitting BKL- Thai Benkan, Thailand
  • Cu. Pipe Fitting Lame S.r.l., Italy
  • Cu. Pipe Fitting Metal far, Italy
  • Cu. Pipe Fitting make Raccortubi S.p.A., Italy
  • Cu. Pipe Fitting make Erne Fitting, Austria
  • Cu. Alloy Pipe Fitting make Melesi, Italy
  • Cu. Pipe Fitting make Mega, Italy
Standards ASME B16.28, BS10, ASME/ANSI B16.9, MSS-SP-43, BS4504, BS4504, BS1560
Fittings Thread BSPT, NPT, BSPP
Available Thickness From Schedule 5s upto XXS available with NACE MR 01-75
Sizes Cu Alloy Seamless Butt Weld Fittings: 1/2" - 10"
Cu Alloy Welded Butt Weld Fittings: 1/2" - 48"
Main Types Welded / Seamless /Fabricated

Threaded Copper Fittings Price List

Description Price Per Kg In Singapore Price Per Kg In UAE Price Per Kg In USD Price Per Kg In Malaysia
15 X 12 COPPER PIPE FITTINGS 601-R REDUCING COUPLING #524 SGD 22.91 UAE Dirham 59.83 US $16.55 MYR 72.56
15 X 12MM COPPER PIPE FITTINGS M607 ELBOW (R) #5090 SGD 38.41 UAE Dirham 100.30 US $27.74 MYR 121.64
15 X 15 X 10B COPPER PIPE FITTINGS 611RB TEE #513 SGD 27.16 UAE Dirham 70.92 US $19.62 MYR 86.01
1/2 X 6000# COUPLING COPPER PIPE FITTINGS COUPLINGS, ELBOWS, SLEEVES SGD 5.94 UAE Dirham 15.51 US $4.29 MYR 18.81
1/4, INLET, D10 COPPER PIPE FITTINGS UNION, BRASS SGD 0.20 UAE Dirham 0.52 US $0.14 MYR 0.63

Check our material dispatch in the following countries

Copper Fittings Manufacturers In India

Copper Pipe Fittings Types

Copper Reducing Tee

Copper Reducing Tee

Threaded Copper 180 Degree Elbows

Threaded Copper 180 Degree Elbows

Copper Stub End

Copper Stub End

ASME B16.22 Copper 45 Degree Elbows

ASME B16.22 Copper 45 Degree Elbows

Industrial Copper Cross Fitting

Industrial Copper Cross Fitting

Cu 90 Degree Elbows

Cu 90 Degree Elbows

Copper Laterals

Copper Laterals

22mm Copper Elbow

22mm Copper Elbow

Cu Cross Tee

Cu Cross Tee

Copper Fittings

Copper Fittings

10mm Copper Concentric Reducer

10mm Copper Concentric Reducer

Copper Equal Tee

Copper Equal Tee

8mm Copper End Cap

8mm Copper End Cap

Cu Eccentric Reducer

Cu Eccentric Reducer

28mm Copper Lap Joint Stub Ends

28mm Copper Lap Joint Stub Ends

Copper Reducer

Copper Reducer

ASME B16.22 Copper Weld Elbows

ASME B16.22 Copper Weld Elbows

Cu Return Bends

Cu Return Bends

Why Select Copper ?

aaaa
  • Superior performance at reasonable cost!
  • Light & Compact
  • Easy to Join
  • Fabrication
  • Corrosion Resistance
  • Flow
  • Safe
  • Dependable

ASME B16.22 Copper Fittings Pressure Rating

ALLOYS USED FOR JOINTS SERVICE TEMPERATURE ºF STANDARD TUBE SIZE,TYPES K, L, AND M
WATER AND NON-CORROSIVE LIQUIDS & GASES
1-1/4 to 2 1/4 to 1 2-1/2 to 4 5 to 8
Alloy HB Solder 100 805 1035 670 625
150 555 710 460 430
200 345 440 285 265
250 335 430 275 260
95 / 5 Tin-Antimony Solder 100 850 1090 705 660
150 485 625 405 375
200 395 505 325 305
250 210 270 175 165
50 / 50 Tin Lead Solder Not to be used in potable water systems 100 175 200 150 135
150 125 150 100 90
200 90 100 75 70
250 75 85 50 45
Alloy E Solder 100 555 710 460 430
150 370 475 305 285
200 290 375 240 225
250 250 320 205 195
Brazing Alloys (melting at or above 1000ºF) Pressure-temperature ratings is that of the tubing being used

Copper 90° Reducing Elbow, Short Radius

Copper 90° Reducing Elbow, Short Radius
BOX QTY OD SIZE (in) APPROX NET WT MASTER PACK
50 1/2 x 3/8 0.026 1000
50 5/8 x 1/2 0.04 500
50 5/8 x 3/8 0.03 500
25 3/4 x 5/8 0.08 250
25 7/8 x 3/4 0.026 500
50 7/8 x 5/8 0.08 500
25 1-1/8 x 5/8 0.12 250
25 1-1/8 x 7/8 0.15 250
10 1-3/8 x 1-1/8 0.23 100
10 1-5/8 x 1-3/8 0.34 100
5 2-1/8 x 1-5/8 0.6 40

Copper Compression Fittings Supplier in India, Check Dimensions and Price list of ASTM B62 Cu Stub End

Industrial Copper Pipe Fittings Dimensions

Weight Chart of Copper Pipe Fittings
STANDARD WATER TUBE SIZE FEMALE END METAL THICKNESS T MALE END INSIDE DIA. OF FITTING O

INSIDE DIA. F DEPTH G
OUTSIDE DIA. A LENGTH K

MIN. MAX. MIN. MIN. MIN. MAX. MIN. MIN.
1/8 0.252 0.256 0.31 0.022 0.248 0.251 0.38 0.18
1/4 0.377 0.381 0.31 0.026 0.373 0.376 0.38 0.3
3/8 0.502 0.506 0.38 0.031 0.497 0.501 0.44 0.39
1/2 0.627 0.631 0.5 0.036 0.622 0.626 0.56 0.52
5/8 0.752 0.756 0.62 0.038 0.747 0.751 0.69 0.63
3/4 0.877 0.881 0.75 0.041 0.872 0.876 0.81 0.74
1 1.128 1.132 0.91 0.046 1.122 1.127 0.97 0.98
1-1/4 1.378 1.382 0.97 0.05 1.372 1.377 1.03 1.23
1-1/2 1.628 1.633 1.09 0.055 1.621 1.627 1.16 1.47
2 2.128 2.133 1.34 0.064 2.121 2.127 1.41 1.94
2-1/2 2.628 2.633 1.47 0.074 2.621 2.627 1.53 2.42
3 3.128 3.133 1.66 0.083 3.121 3.127 1.72 2.89
3-1/2 3.628 3.633 1.91 0.093 3.621 3.627 1.97 3.37
4 4.128 4.133 2.16 0.101 4.121 4.127 2.22 3.84
5 5.128 5.133 2.66 0.115 5.121 5.127 2.72 4.7
6 6.128 6.133 3.09 0.13 6.121 6.127 3.22 5.72
8 8.128 8.133 3.97 0.186 8.119 8.127 4.09 7.55

ASME B16.22 Copper Tee

ASME B16.22 Copper Tee
BOX QTY OD SIZE (in) APPROX NET WT MASTER PACK
50 3/16 0.009 1000
50 1/4 0.015 1000
50 5/16 0.02 1000
50 3/8 0.028 1000
50 1/2 0.047 500
50 5/8 0.05 500
25 3/4 0.1 250
25 7/8 0.16 250
10 1-1/8 0.33 100
5 1-3/8 0.46 50
5 1-5/8 0.71 50
5 2-1/8 1.29 40
1 2-5/8 1.9 10
1 3-1/8 2.75 10
1 3-5/8 4.17 8
1 4-1/8 6.62 8

Cu Buttweld Fitting Chemical Composition

Chemical Composition
P% CU%
0.015 to 0.040 >99.9

Copper Fittings Mechanical Properties

Mechanical Properties
Tensile Properties (Mpa) Temper Average Grain Size (mm) Elongation (%)
>205 >60 >0.040 >40
>245 >50

22mm Copper Pipe Fittings Equivalent

Copper NO. Standard
C12200 ASTM
B280/68
Buy Copper Seamless Fittings at dealer Price for Oil And Gas Industry, Stockist of Copper End Cap in Mumbai

Cu pipe fittings Applications

  • HVAC Industry

  • Electrical Industry

  • Plumbing Sanitary Ware Industry

  • MGPS Industry

  • Constructions Industry

  • Automobiles Industry

  • Water & Gas Industry

  • Electrical Engineering Industry

  • Marine Engineering Industry

  • Earthing Systems Industry

Copper Pipe Fittings Equivalent Length

Nominal Size
(in)
Equivalent Length (feet)
45o Elbow  90o Elbow Ball Valve Line 90o Tee Branch 90o Tee Butterfly Valve Gate Valve Check Valve
0.5 3/8 1.5 1.5
1/2 0.5 1 2 2
5/8 0.5 1.5 2 2.5
3/4 0.5 2 3 3
1 1 2.5 0.5 4.5 4.5
1 1/4 1 3 0.5 5.5 0.5 5.5
1 1/2 1.5 4 0.5 7 0.5 6.5
2 2 5.5 0.5 9 0.5 7.5 0.5 9
2 1/2 2.5 7 12 0.5 10 1 11.5
3 3.5 9 15 1 15.5 1.5 14.5
3 1/2 3.5 9 14 1 2 12.5
4 5 12.5 21 1 16 2 18.5

Dimensions Of Soldered Types Copper Fittings

Dimensions Of Soldered Types Copper Fittings
Why don't you directly contact a Copper 90 Degree Elbow manufacturer in Mumbai? We offer ASME SB62 Cu Stub End in India

Cu Plumbing And Gas Lines Tubes

OD of Tube (mm) 42 15 22 76.1 12 108 28 67 35 54
Table‘X’ Maximum Working Pressure (bar) 35 59 51 23 64 17 41 19 43 27
Table‘X’ Nominal Thickness (mm) 1.2 0.7 0.9 1.5 0.6 1.5 0.9 1.2 1.2 1.2
Table‘Y’ Nominal Thickness (mm) 1.5 1.0 1.0 2.0 0.8 2.5 1.2 2 1.5 2.0
Table‘Z’ Nominal Thickness (mm) 0.8 0.5 0.6 1.2 0.5 1.2 0.6 1.2 0.7 0.9
Table‘Y’ Maximum Working Pressure (bar) 45 87 69 32 87 29 55 36 54 47
Table‘Z’ Maximum Working Pressure (bar) 29 51 41 19 62 17 32 20 31 26

Copper 45° Elbow

Copper 45° Elbow
OD SIZE (in) MASTER PACK BOX QTY APPROX NET WT
1/4 1000 50 0.005
3/8 1000 50 0.011
3/8 -- 50 --
1/2 1000 50 0.02
5/8 1000 100 0.03
5/8 -- 100 --
3/4 250 25 0.06
3/4 -- 25 --
7/8 500 50 0.08
7/8 -- 50 --
1-1/8 250 25 0.15
1-1/8 -- 25 --
1-3/8 200 25 0.23
1-5/8 160 20 0.34
2-1/8 80 10 0.62
2-5/8 40 5 0.97
3-1/8 24 3 1.44
3-5/8 16 1 2.14
4-1/8 8 1 3.1
