20 Years old ASTM A182 F304L Threaded Elbow Manufacturer in India, Check 304L SS Socket Weld Tee Dimensions and Price list

304L Stainless Steel Socket Weld Fittings

The 304l are forged low-carbon austenitic grade fittings of stainless steel. The versatile Stainless Steel 304L Forged Fittings are robust components that play a pivotal role in changing, terminating, and joining piping equipment of dissimilar sizes and shapes. The robust SS 304L Forged Fittings have enhanced corrosion resistance properties due to their superior chemical composition. These fittings can be readily welded following standard welding procedures. 304L Stainless Steel Forged Fittings are generally forged at temperatures between 800 to 1000 degrees C. These fittings can be readily heat-treated and normalized as per requirements. The ASTM A182 F304L Forged Fittings are forged at extreme pressures as they are stuck to precisely shape the fittings. These fittings can be either hot or cold rolled in different specifications. They can be hardened at temperatures between 750 to 950 degrees C. The SA 182 F304L Fittings are pressurized vessel grade that has outstanding surface porosity and a finer grain structure. These fittings have outstanding fatigue strength and performance.

The Stainless Steel 304L Threaded Fittings are designed with threads that help align to subsequent equipment. These fittings are easy to install and can be readily dismantled. They are seen in low-pressure and temperature setups. SS 304L Socket Weld Fittings have a recessed socket that allows the pipe attachment detail to be inserted and welded to the module using a single fillet weld. These fittings are seen in smaller diameter piping equipment. They are available in different specifications to meet all our requirements.

Supplier of ASTM A182 F304L Socket Weld Union offers Safely Pressure Test to ensure strength and quality, View Weight Chart of Werkstoff No 1.4306 Threaded Pipe Nipple

304L Stainless Steel Socket Weld Fittings Specification

Here are many benefits if you buy from 304L Stainless Steel Socket Weld Fittings manufacturers, like high quality, best price and wide range of ASTM A182 304L Stainless Steel Forged Fittings

Specification ASTM/ ASME A182 / SA182
Class 3000 LBS, 9000 LBS, 2000 LBS, 6000 LBS
Type Screwed-Threaded Fittings and Socketweld Fittings
Standard MSS SP-83, 79, 97, 95, ASME 16.11, BS 3799
Sizes From 1/8” NB to 4” NB

ASTM A182 304L Stainless Steel Forged Fittings Price List

Description Price Per Kg In Singapore Price Per Kg In UAE Price Per Kg In USD Price Per Kg In Malaysia
1CL 3000 EQUAL TEE ASTM A182 304L DUAL MARKE SOCKET WELDED ASME B16.11 SGD 24.14 UAE Dirham 63.03 US $17.43 MYR 76.44
1-1/2 NPS SS,5.08MM (0.2000) WALL THK/S80S, STAINLESS STEEL FITTING GRADE 304L TEE PIPE, SOCKET WELD, ASTM A 182 SGD 11.50 UAE Dirham 30.03 US $8.31 MYR 36.42
CL3000 STAINLESS STEEL FITTINGS ELBOW PIPE SOCKET WELD OR THREADED AL ELBOW SW ASME B16.11 A182-F304L SGD 6.34 UAE Dirham 16.54 US $4.58 MYR 20.06
1 CL3000 PIPE FITTINGS FORGED COUPLING HALF ASME SA182 F304L IBR SOCKET WELDED ASME B16.9 SGD 839.05 UAE Dirham 2,190.86 US $605.98 MYR 2,657.00
1/2 CL3000 PIPE FORGED COUPLING HALF ASME SA182 F304L IBR SOCKET WELDED ASME B16.9 SGD 74.92 UAE Dirham 195.61 US $54.11 MYR 237.23
2 CL 3000 45 DEG LR ELBOW ASTM A182 F304L SOCKET WELDED ASME B16.11 SGD 89.19 UAE Dirham 232.89 US $64.42 MYR 282.44

Stainless Steel 304L Forged Fittings Types

304L Stainless Steel Socket Weld Union

304L Stainless Steel Socket Weld Union

SS 304L Socket Weld Caps

SS 304L Socket Weld Caps

ASTM A182 304L Stainless Steel Threaded Coupling

ASTM A182 304L Stainless Steel Threaded Coupling

Stainless Steel 304L Threaded Tee

Stainless Steel 304L Threaded Tee

ASTM A182 Grade 304 SS Threaded Union

ASTM A182 Grade 304 SS Threaded Union

SS 304L Threaded Caps

SS 304L Threaded Caps

Stainless Steel ASTM A182 304L Socket Weld Coupling

Stainless Steel ASTM A182 304L Socket Weld Coupling

ASTM A182 Gr 304 SS Square Plugs

ASTM A182 Gr 304 SS Square Plugs

304L Stainless Steel Socket Weld Fittings

304L Stainless Steel Socket Weld Fittings

SS 304L Threaded Elbow

SS 304L Threaded Elbow

Werkstoff No 1.4307 SS Socket Weld Cross

Werkstoff No 1.4307 SS Socket Weld Cross

ASME SA182M Stainless Steel 304L Threaded Cross

ASME SA182M Stainless Steel 304L Threaded Cross

SS 304L Hexagon Bushing

SS 304L Hexagon Bushing

ASTM A182 F304L Stainless Steel Hexagon Plugs

ASTM A182 F304L Stainless Steel Hexagon Plugs

304L Stainless Steel Socket Weld Tee

304L Stainless Steel Socket Weld Tee

ASTM A182 304 Stainless Steel Threaded Bends

ASTM A182 304 Stainless Steel Threaded Bends

ASME SA182 304 Stainless Steel Socket Weld Lateral Tee

ASME SA182 304 Stainless Steel Socket Weld Lateral Tee

SA 182 Gr 304 SS Socket Weld Elbow

SA 182 Gr 304 SS Socket Weld Elbow

SS 304L Adapter Threaded Chart

3000LB

SS 304L Adapter Threaded Chart
D DN Threaded Size
B
Nom Pipe Size
A
L
19 8 1/8" 1/4" 33
22 10 1/4" 3/8" 35
28 15 3/8" 1/2" 42
35 20 1/2" 3/4" 47
44 25 3/4" 1" 55
57 32 1" 1-1/4" 63
64 40 1-1/4" 1-1/2" 66
76 50 1-1/2" 2" 76
92 65 2" 2-1/2" 90
108 80 2-1/2" 3" 110
140 100 3" 4" 120

304L Stainless Steel Branch Outlet Socket Weld Fittings Size Chart

Save 10-12% if you buy directly from Stainless Steel 304L Forged Fittings manufacturers

304L Stainless Steel Branch Outlet Socket Weld Fittings Size Chart
Out-Let Pipe NPS Reducing Way
C D F J (Min) E (Min)
6000 3000 3000 6000 6000 3000 6000 3000 3000 6000
1/8" 13.7 10.8 22.0 9.7 10.4
1/4" 13.7 14.2 22.0 9.7 10.4
3/8" 19.1 17.6 25.9 9.7 12.7
1/2" 16.6 21.3 21.8 21.8 38.0 31.4 9.7 9.7 16.0 23.9
3/4" 21.2 26.7 27.2 27.2 44.0 37.1 12.7 12.7 16.0 25.4
1" 27.0 33.4 33.9 33.9 57.0 45.5 12.7 12.7 22.4 28.7
1-1/4" 35.8 42.2 42.7 42.7 64.0 57.0 12.7 12.7 22.4 30.2
1-1/2" 41.2 48.3 48.8 48.8 76.0 64.0 12.7 12.7 23.9 31.8
2" 51.6 60.3 61.2 61.2 92.0 76.0 15.8 15.8 23.9 36.6
2-1/2" 73.2 73.9 92.0 15.8 25.4
3" 88.9 89.8 109.2 15.8 30.2
4" 114.3 115.2 140.0 19.1 30.2

Out-Let Pipe NPS Straight Way
C D F J (Min) E (Min)
3000
1/4" 11.5 14.2 22.0 9.7 10.4
1/8"
3/8" 14.5 17.6 25.9 9.7 12.7
3/4" 21.5 27.2 37.1 12.7 16.0
1/2" 16.5 21.8 31.4 9.7 16.0
1" 27.2 33.9 45.5 12.7 22.4
1-1/2" 42.0 48.8 64.0 12.7 23.9
1-1/4" 36.0 42.7 57.0 12.7 22.4
2" 53.0 61.2 76.0 15.8 23.9
3" 80.0 89.8 109.2 15.8 30.2
2-1/2" 65.0 73.9 92.0 15.8 25.4
4" 104.0 115.2 140.0 19.1 30.2

We stock a wide range of Stainless Steel 304L Threaded Fittings and AISI 310 Forged Coupling in wide range of Pressure rating and sizes To Meet All Your Needs.

ASTM A182 304L Stainless Steel Plug and Bushing Sizes

ASTM A182 304L Stainless Steel Plug and Bushing Sizes
DN Length (Min.)
A
Round Head Plug Nom. Pipe Size Square Head Plug Hex. Head Plug & Bushing
Nominal Diameter of Head (Nom) E Length (Min.)
D
Height of Square (Min.)
B
Width Flat (Min.)
C
Width Flat (Nom.)
F
Hex. Height (Min.)
Plug
H
Bushing
G
6 10 10 35 1/8” 6 7
6
8 11 14 41 1/4” 6 10 16 6 3
10 13 18 41 3/8” 8 11 18 8 4
15 14 21 44 1/2” 10 14 22 8 5
20 16 27 44 3/4” 11 16 27 10 6
25 19 33 51 1” 13 21 36 10 6
32 21 43 51 1-1/4” 14 24 46 14 7
40 21 48 51 1-1/2” 16 28 50 16 8
50 22 60 64 2” 18 32 65 18 9
65 27 73 70 2-1/2” 19 36 75 19 10
80 28 89 70 3” 21 41 90 21 10
100 32 114 76 4” 25 65 115 25 13

SS 304L Forged Fittings Chemical Composition

We are a specialist distributor & supplier of SS 304L Forged Fittings and Stainless Steel 304L Forged Elbow

Cr Mn C Ni P S Si Mo N
18 – 20 2.0 max 0.035 max 8 – 13 0.045 max 0.03 max 1.0 max - -

Werkstoff No 1.4307 SS High Pressure Forged Fittings Mechanical Properties

(0.2%Offset) Yield Properties Melting Point Density Tensile Properties Elongation
Psi – 30000 , MPa – 205 1400 °C (2550 °F) 8.0 g/cm3 Psi – 75000 , MPa – 515 35 %

ASME SA182M Stainless Steel 304L Fittings Equivalent

AFNOR UNS BS WERKSTOFF NR. GOST JIS EN
Z3CN18‐10 S30403 3304S11 1.4306 / 1.4307 03Х18Н11 SUS 304L X2CrNi18-9 / X2CrNi19-11
Are you looking for leading SA 182 F304L Threaded Plug Manufacturer in India, We are exporter and stockist of SS 304L Socket Weld Fittings

SS 304L Forged Pipe Fittings Applications

Why don't you directly contact a SS 304L Threaded Fittings manufacturer in India? We offer an extensive range of Stainless Steel ASTM A182 304L Cross and SS 304L Socket weld Fittings in Mumbai, free sample before dispatch of complete order.

  • Petrochemical Industry

  • Pharmaceuticals Industry

  • Pulp & Paper Industry

  • Power Plant Industry

  • Energy Industry

  • Refining Industry

  • Aerospace Industry

  • Food Processing Industry

  • Chemical Industry

  • Oil and Gas Industry

Stainless Steel 304L Socket Fittings Dimensions

Stainless Steel 304L Socket Fittings Dimensions
DN Socket Wall Thickness (2) C Nom. Pipe Size Body Wall Thickness G Center to Bottom of Socket-A Socket Bore Dia.
B
Bore Dia. Of Fitting D Depth of Socket Min. J
Class Designation Class Designation 90° Elbows Tees, Crosses 45° Elbows
3000 6000 9000 6000 3000 9000 Class Designation Class Designation Class Designation
Ave. Min Ave. Min Ave. Min Min. Min. Min. 3000 6000 9000 6000 3000 9000 3000 6000 9000
6 3.18 3.18 3.96 3.43 1/8” 3.15 2.41 11.0 11.0 8.0 8.0 10.8 6.9 4.0 9.5
8 3.78 3.30 4.60 4.01 1/4” 3.68 3.02 11.0 13.5 8.0 8.0 14.2 9.3 6.4 9.5
10 4.01 3.50 5.03 4.37 3/8” 4.01 3.20 13.5 15.5 11.0 8.0 17.6 12.6 9.2 9.5
15 4.67 4.09 5.97 5.18 9.35 8.18 1/2” 4.78 3.73 7.47 15.5 19.0 25.5 12.5 11.0 15.5 21.8 15.8 11.8 6.4 9.5
20 4.90 4.27 6.96 6.04 9.78 8.56 3/4” 5.56 3.91 7.82 19.0 22.5 28.5 14.0 13.0 19.0 27.2 21.0 15.6 11.1 12.5
25 5.69 4.98 7.92 6.93 11.38 9.96 1” 6.35 4.55 9.09 22.5 27.0 32.0 17.5 14.0 20.5 33.9 26.7 20.7 15.2 12.5
32 6.07 5.28 7.92 6.93 12.14 10.62 1-1/4” 6.35 4.85 9.70 27.0 32.0 35.0 20.5 17.5 22.5 42.7 35.1 29.5 22.8 12.5
40 6.35 5.54 8.92 7.80 12.70 11.12 1-1/2” 7.14 5.08 10.15 32.0 38.0 38.0 25.5 20.5 25.5 48.8 40.9 34.0 28.0 12.5
50 6.93 6.04 10.92 9.50 13.84 12.12 2” 8.74 5.54 11.07 38.0 41.0 54.0 28.5 25.5 28.5 61.2 52.5 42.9 38.2 16.0
65 8.76 7.67 2-1/2” 7.01 41.0 28.5 73.9 62.7 16.0
80 9.52 8.30 3” 7.62 57.0 32.0 89.8 78.0 16.0
100 10.69 9.35 4” 8.56 66.5 41.0 115.2 102.3 19.0

ASTM A182 F304L Stainless Steel Forged Fittings Weight Chart

Buy Werkstoff No 1.4307 SS High Pressure Forged Fittings and ASME SA182M Stainless Steel 304L Fittings at wholesale rate directly from manufacturers in India

Thread Fittings

Size Product 1/4” 1/2” 2” 3/4” 1/8” 4” 1” 1-1/2” 3/8” 1-1/4” 2-1/2” 3”

45 Elbow
2000 0.08 0.20 1.41 0.27 0.09 8.96 0.41 0.82 0.10 0.68 3.46 5.44
3000 0.12 0.34 2.23 0.56 0.09 8.96 0.94 2.05 0.24 1.03 3.71 5.97
6000 0.27 0.63 4.37 1.07 0.11 11.36 1.27 2.54 0.39 2.24 7.01 14.16

90 Elbow
2000 0.08 0.25 1.70 0.35 0.10 10.21 0.53 1.06 0.13 0.82 3.14 4.81
3000 0.14 0.43 2.92 0.69 0.10 14.85 1.14 2.63 0.29 1.42 5.99 8.88
6000 0.33 0.80 7.31 1.31 0.17 15.76 1.61 3.79 0.45 2.93 9.88 17.73

Tee
2000 0.12 0.31 2.16 0.43 0.13 14.74 0.69 1.39 0.17 1.07 4.11 6.12
3000 0.20 0.56 3.53 0.92 0.13 19.13 1.49 3.27 0.38 1.76 6.99 10.19
6000 0.45 0.98 7.88 1.65 0.20 18.53 2.17 4.71 0.63 3.74 13.11 21.70
Cross 2000 0.14 0.39 2.65 0.54 0.17 16.35 0.83 1.75 0.21 1.26 5.26 7.58
3000 0.26 0.72 4.27 1.06 0.17 21.93 1.79 3.93 0.44 2.13 8.51 12.45
Half Coupling 3000 0.02 0.06 0.70 0.10 0.02 3.11 0.23 0.54 0.03 0.34 1.13 1.68
6000 0.06 0.16 1.70 0.24 0.07 5.02 0.45 0.96 0.09 0.55 2.10 3.05
Round Head Plug 0.45 0.12 1.47 0.20 0.02 6.24 0.34 0.79 0.07 0.55 2.34 3.26
Red Coupling 3000 0.05 0.13 1.37 0.19 0.05 5.44 0.39 0.99 0.06 0.68 2.07 3.08
6000 0.06 0.31 3.40 0.41 0.08 10.04 0.85 1.81 0.18 1.05 4.20 6.10
Full Coupling 3000 0.04 0.13 1.40 0.19 0.05 6.28 0.45 1.07 0.06 0.81 2.29 3.38
6000 0.13 0.34 2.87 0.50 0.08 10.04 0.87 1.94 0.20 1.09 4.20 6.10
Cap 3000 0.04 0.11 1.09 0.18 0.02 4.84 0.37 0.72 0.05 0.62 2.22 3.50
6000 0.06 0.26 2.23 0.40 0.06
0.71 0.77 0.09 0.59

Street Elbow 3000 0.11 0.31 2.91 0.53 0.13
1.02 2.01 0.22 1.13

Union 3000 0.28 0.34 2.43 0.48 0.28 12.00 0.77 1.63 0.24 1.03 3.63 5.27
Square Head Plug 0.01 0.05 0.63 0.09 0.01 3.83 0.16 0.38 0.03 0.27 0.96 1.53
Hex. Nipple 3000 0.04 0.09 1.03 0.15 0.03 4.00 0.47 0.62 0.05 0.45 1.51 2.22
Hex. Head Plug 0.03 0.07 1.03 0.14 0.01 5.20 0.22 0.59 0.05 0.44 1.80 2.60
Hex. Head Bushing 0.01 0.03 0.45 0.05
3.20 0.09 0.34 0.01 0.25 0.60 1.16

Socket Weld Fittings

Size Product 2” 1/4” 3/8” 3/4” 1” 1/2” 1/8” 3” 1-1/4” 4” 1-1/2” 2-1/2”
Cap 3000 0.96 0.04 0.07 0.16 0.25 0.10 0.03 2.74 0.45 4.24 0.59 1.43
6000 1.41 0.08 0.10 0.23 0.36 0.16 0.05 0.64 0.94
90 Elbow 3000 1.68 0.08 0.12 0.33 0.53 0.22 0.09 5.38 0.84 10.95 1.08 3.20
6000 3.28 0.15 0.29 0.73 1.17 0.40 0.10 1.48 2.79
Tee 3000 2.04 0.09 0.15 0.42 0.65 0.29 0.13 5.90 1.04 13.92 1.35 3.98
6000 3.95 0.20 0.43 0.94 1.49 0.56 0.14 1.93 3.37
45 Elbow 3000 1.35 0.07 0.11 0.28 0.42 0.20 0.08 5.10 0.69 9.41 0.80 2.53
6000 2.09 0.14 0.26 0.57 0.92 0.36 0.09 1.11 2.01
Full Coupling 3000 0.86 0.05 0.07 0.17 0.29 0.13 0.04 1.78 0.45 2.85 0.59 1.40
6000 1.62 0.07 0.114 0.27 0.44 0.204 0.05 0.60 1.11
Cross 3000 2.25 0.13 0.20 0.47 0.73 0.35 0.16 6.69 1.12 14.58 1.58 4.37
6000 4.42 0.26 0.45 1.07 1.75 0.67 0.17 2.26 3.96
Half Coupling 3000 1.09 0.05 0.07 0.21 0.30 0.13 0.04 2.10 0.34 3.71 0.66 1.63
6000 1.92 0.09 0.12 0.31 0.51 0.21 0.06 0.75 1.25
Red Coupling 3000 0.97 0.05 0.07 0.19 0.27 0.13 0.04 1.88 0.49 3.31 0.59 1.42
6000 2.12 0.33 0.65 0.24 0.75 1.20
Union 3000 2.16 0.28 0.25 0.49 0.81 0.35 0.28 5.15 1.10 11.59 1.61 3.50
Check UNS S30403 Bushing / Hex Nipple and 304L Stainless Steel Forged Fittings pressure rating & price in India

SS 304L Threaded Fittings Dimensions

SS 304L Threaded Fittings Dimensions
DN Center to End 45° Elbow C
Nom. Pipe Size
Center to End Elbow, Tee, Cross A Length of Thread Min. (1) Minimum Wall Thickness G Outside Diameter Of Band H
3000 2000 6000 3000 2000 6000 B L2 2000 6000 3000 2000 3000 6000
6 17 17 19 1/8” 21 21 25 6.4 6.7 3.18 6.35 3.18 22 22 25
8 19 17 22 1/4” 25 21 28 8.1 10.2 3.18 6.60 3.30 22 25 33
10 22 19 25 3/8” 28 25 33 9.1 10.4 3.18 6.98 3.51 25 33 38
15 25 22 28 1/2” 33 28 38 10.9 13.6 3.18 8.15 4.09 33 38 46
20 28 25 33 3/4” 38 33 44 12.7 13.9 3.18 8.53 4.32 38 46 56
25 33 28 35 1” 44 38 51 14.7 17.3 3.68 9.93 4.98 46 56 62
32 35 33 43 1-1/4” 51 44 60 17.0 18.0 3.89 10.59 5.28 56 62 75
40 43 35 44 1-1/2” 60 51 64 17.8 18.4 4.01 11.07 5.56 62 75 84
50 44 43 52 2” 64 60 83 19.0 19.2 4.27 12.09 7.14 75 84 102
65 52 52 64 2-1/2” 83 76 95 23.6 28.9 5.61 15.29 7.65 92 102 121
80 64 64 79 3” 95 86 106 25.9 30.5 5.99 16.64 8.84 109 121 146
100 79 79 79 4” 114 106 114 27.7 33.0 6.55 18.67 11.18 146 152 152

ASTM A182 F304L Stainless Steel Lateral Outlet Socket Weld Fittings

Why pay extra? Buying from SS 304L Forged Pipe Fittings manufacturers saves your cost, wide selection of ASTM A182 F304L Stainless Steel Forged Fittings and 304L Stainless Steel Socket Weld Fittings in India

ASTM A182 F304L Stainless Steel Lateral Outlet Socket Weld Fittings

3000LB

D Outlet Pipe C A F J
Inch DN
14.35 1/4” 8 35.2 40.5 22.0 10.0
17.80 3/8” 10 35.2 40.5 25.9 10.0
21.95 1/2” 15 35.2 40.5 31.4 11.1
27.30 3/4” 20 43.6 47.6 37.1 12.7
34.05 1” 25 54.0 55.6 45.5 13.5
42.80 1-1/4” 32 67.5 60.3 57.0 15.1
48.90 1-1/2” 40 76.2 66.7 64.0 15.9
61.35 2” 50 104.8 81.0 76.0 17.5
74.15 2-1/2” 65 106.4 82.6 92.0 23.8
90.10 3” 80 125.4 96.8 109.2 28.6
115.75 4” 100 163.5 114.3 140.0 29.4

6000LB

A Outlet Pipe C D F J
DN Inch
40.5 8 1/4” 34.9 14.35 26.0 10.0
40.5 10 3/8” 34.9 17.80 33.0 10.0
47.6 15 1/2” 34.9 21.95 38.0 10.0
55.6 20 3/4” 43.6 27.30 44.0 14.3
60.3 25 1” 54.0 34.05 57.0 15.9
66.7 32 1-1/4” 67.5 42.80 64.0 20.6
85.7 40 1-1/2” 76.2 48.90 76.0 20.6

Check our reference of material in these countries

ADCO - Onshore Gas Gathering & Injection For OGD3-Dubai

ADCO - Onshore Gas Gathering & Injection For OGD3-Dubai

Qatar Petrochemical Company

Qatar Petrochemical Company

Malampaya Project Phase 3 Luzon, Philippines

Malampaya Project Phase 3 Luzon, Philippines

Tanzania LNG Liquefaction Plant-South Africa

Tanzania LNG Liquefaction Plant-South Africa

Lake Charles Lng Liquefaction Plant-USA

Lake Charles Lng Liquefaction Plant-USA

Origin Energy Limited Australia

Origin Energy Limited Australia
