ASTM A182 F61 Flange

Available Sizes :

• NPS: ½" to 24"
• DN15 To DN1500
• PN2.5 To PN400
• Contact ASTM A182 F61 flange manufacturer in India for above 48 Inch

Pressure Level :

• 150# and 300#
• 600# and 900#
• 1500# and 2500#

Manufacturing Standard :

• ASME B16.36
• ASME B16.5
• ASME B16.47
• ASME B16.48

Size (Maximum) :

• 26" To 60" As Per ASME B16.47

Manufacturing Process :

• Cast
• Plate
• Forged

Number of Bolts Hole :

• 4 To 48

A182 F61 Forging Temperature :

• 2100°F to 2300°F

Advantages :

• Improved Wear Resistance

Surface Finish :

• Polished finish
• Mirror finish
• Stock finish

Design Temperature (Minimum) :

• -50°F to -100°F

Flange Face :

• RTJ Face
• Male & Female Face
• RF Face
• FF Face
• Tongue & Groove Face

Types Of Threads :

• FPT Threads
• BSPT Threads
• MPT & MNPT Threads
• NPT Threads
• BSP Threads

Common Thickness :

• SCH 10/ 20/ 40
• SCH 60/ 80/ 100
• SCH 120/ 140/ 180

Application :

• Oil & gas plants
• Petrochemicals
• Power Generation
• Nuclear Energy

Testing Checklist :

• Hardness test
• PMI test
• Tensile test
• Impact test
• Material inspection

Melting Point

• 1399°C to 1454°C

End Connection :

• Threaded
• Welding

Marking Info :

• Size & Schedule
• Standard & Heat No.
• Grade & Material
• Manufacturers Name

UNS :

• UNS S32950

Germany Standards (DIN) :

• DIN 2576
• DIN 2561
• DIN 2632
• DIN 2633
• DIN 2527
• DIN 2501

European Standards (EN) :

• EN 1092-1
• EN 1092-2
• EN 1092-1 TYPE 01
• EN 1092-1 TYPE 02
• EN 1092-1 TYPE 05
• EN 1092-1 TYPE 11
• EN 1092-1 TYPE 13

Japanese Standard (JIS) :

• JIS B2220

AWWA Standard :

• AWWA c207

BS Standard :

• BS4504

Value Added Services :

• Threading
• Minor Fabrication
• Beveling end
• Polishing
• Casting

Logistics :

• By Sea
• By Air
• UAE = 5 day
• Bahrain = 9 day
• Kuwait = 10 day
• Malaysia = 10 day
• Philippines = 14 day
• Singapore = 8 days
• Indonesia = 9 days
• Oman = 5 days

Types Of Packaging :

• Wooden Cases
• Wooden Pallet
• Carton Box

Grade :

• ASTM A182 F61 Flange

UNS :

• UNS S32950

WNR :

• 1.4410

Carbon [C] :

• 0.040%

Manganese [Mn] :

• 1.50%

Phosphorus [P] :

• 0.040%

Sulfur [S] :

• 0.030%

Silicon [Si] :

• 1.00%

Chromium [Cr] :

• 24.00 To 27.00%

Molybdenum [Mo] :

• 2.9 To 3.9%

Nickel [Ni] :

• 4.5% To 6.5%

Nitrogen [N] :

• 0.10% To 0.25%

Density :

• 7.80 g/cm³

Melting Point :

• 1375°C To 1410°C

Thermal Conductivity :

• 14.5 W/m·K

Specific Heat Capacity :

• 500 J/kg·K
