ASTM A234 WP1 Fittings

Fittings help in connecting different piping grades that allow it to change the direction, route the line, and branch different connections. The ASTM A234 WP1 Fittings help in influencing the characteristics of media in different conditions. The fittings are common in the oil and gas industry due to their unique strength and tolerance. WP1 Fittings work well in different corrosive environments and are designed in sizes of 1/8 NB to 48 NB. These fittings are designed in wall thickness between 5S to 160 and XXS. They can be produced in seamless, welded, and fabricated types. The A234 WP1 Material possesses excellent mechanical properties. They possess a minimum tensile strength of 220mpa with a minimum yield strength of 415mpa. The material possesses a hardness between 121 to 174 HB and can be easily elongated by 20% in the system.

The ASTM A234 Gr WP1 Elbow is installed between two lengths of a piping grade that allow it to change the direction of the flow. These elbows are utilized to change the direction of flow by 90, 45, and 22.5 degrees. An SA 234 WP1 Buttweld Elbow is a high-strength fitting that is categorized by long or short radius specifications. These elbows can be employed at different pressures and temperatures. The ASTM A234 WP1 Pipe cap is used to close the end of the piping grade. These caps help in protecting the grade as it is transported or stored against damage or corrosive affluents. A234 Gr WP1 Tee is designed in the shape of a T, having two outlets placed at 90-degrees with the main line pipe. These tees are available in equal and reducing sizes. The A234 WP1 Reducer is utilized to join piping components of dissimilar sizes. The reducer makes a gradual change in the diameter. They can be produced in standard concentric and eccentric configurations.

Exporter of A234 Gr WP1 Tee in India, View available Alloy Steel WP1 Stub End sizes and types available in stock

Alloy Steel A234 WP1 Buttweld Pipe Fittings Specification

Grade Alloy Steel ASTM A234 WP1 Fittings
Standards ASTM/ ASME A234/ SA234
Type Seamless, Welded
Dimension Standard ASME B16.28, ASME/ANSI B16.9, MSS-SP-43
Thickness Sch 5s upto Sch XXS
Types of Butt weld Fittings Equal Tee, 90 Deg Elbow, Short Radius Elbow, Tee, Elbows, Long Stubend, 5D Elbow, Reducer, Bend, Cap, 45 Deg Elbows, Piggable Bend, Nipple, End Cap, 180 Deg Elbow, Short Stubend, Long Radius Elbow, Concentric Reducer, Reducing Tee, Barrel Nipple, Stubend, 3D Elbow, Eccentric Reducer, 1D Elbow, Swage Nipple, Reducing Nipple, Long Radius Bend ASTM A234 WP1 Fittings
Size 1/2" upto 24"
Two Joint / Two Halve Size 6" upto 48"

Chrome Moly A234 WP1 Pipe Fittings Price List

10-12% price difference if you buy directly from Alloy Steel WP1 Butt Weld Fittings manufacturers

Description Price Per Kg In Singapore Price Per Kg In UAE Price Per Kg In USD Price Per Kg In Malaysia
SIZE 1.1/4 SCH40 CARBON STEEL SEAMLESS PIPE FITTING ASTM A234 WP1 B16.9 SMLS 90 ELBOW SGD 0.63 UAE Dirham 1.65 US $0.46 MYR 2.00
32 THK 27.75MM ASME B16.9 SEAMLESS PIPE FITTINGS-90 DEG LR ELBOW ASTM A234 GR WP1 BEVELLED END SGD 7.79 UAE Dirham 20.35 US $5.63 MYR 24.68
38 36 THK 32.95MM X THK 31.21MM ASME B16.9 SMLS ECCENTRIC REDUCER ASTM A234 GR WP1 BEVELLED END SGD 8.60 UAE Dirham 22.47 US $6.21 MYR 27.25
28 THK 25.14MM ASME B16.9 SEAMLESS PIPE FITTINGS-90 DEG LR ELBOW ASTM A234 GR WP1 BEVELLED END SGD 8.86 UAE Dirham 23.12 US $6.40 MYR 28.04
32 24 THK 28.74MM X SCH 60 ASME B16.9 SMLS ECCENTRIC REDUCER ASTM A234 GR WP1 BEVELLED END SGD 7.81 UAE Dirham 20.40 US $5.64 MYR 24.74
26 THK 23.34 MM ASME B16.9 SEAMLESS 45 DEG LR ELBOW ASTM A234 GR WP1 BEVELLED END SGD 7.87 UAE Dirham 20.54 US $5.68 MYR 24.91
SIZE 2X1 SCH80 ASTM A234 WP1 B16.9SMLS CARBON STEEL SEAMLESS PIPE FITTING TEE SGD 0.79 UAE Dirham 2.07 US $0.57 MYR 2.51

Alloy Steel ASTM A234 WP1 Fittings Types

ASTM A234 WP1 Elbow

ASTM A234 WP1 Elbow

WP1 Fittings Stub End

WP1 Fittings Stub End

ASTM A234 WP1 Fittings

ASTM A234 WP1 Fittings

CrMo ASTM A234 WP1 Concentric Reducer

CrMo ASTM A234 WP1 Concentric Reducer

A234 WP1 End Cap

A234 WP1 End Cap

A234 Gr WP1 Reducer

A234 Gr WP1 Reducer

Alloy Steel A234 WP1 Cross Fitting

Alloy Steel A234 WP1 Cross Fitting

ASME SA 234 WP1 Cross Tee

ASME SA 234 WP1 Cross Tee

ASTM A234 Gr WP1 Lap Joint Stub Ends

ASTM A234 Gr WP1 Lap Joint Stub Ends

ASTM A234 WP1 Weld Elbows

ASTM A234 WP1 Weld Elbows

CrMo ASTM A234 WP1 180 Degree Elbows

CrMo ASTM A234 WP1 180 Degree Elbows

A234 WP1 Laterals

A234 WP1 Laterals

A234 Gr WP1 45 Degree Elbows

A234 Gr WP1 45 Degree Elbows

Alloy Steel A234 WP1 Reducing Tee

Alloy Steel A234 WP1 Reducing Tee

ASME SA 234 WP1 Return Bends

ASME SA 234 WP1 Return Bends

ASTM A234 Gr WP1 Eccentric Reducer

ASTM A234 Gr WP1 Eccentric Reducer

A234 Gr WP1 90 Degree Elbows

A234 Gr WP1 90 Degree Elbows

Alloy Steel A234 WP1 Equal Tee

Alloy Steel A234 WP1 Equal Tee

ASTM A234 Alloy Steel WP1 Fittings Pressure Rating

Temperature Ratings Pressure Class
150 300
1 1/4 - 2 Inches 1/4 - 1 Inches 2 1/2 - 3 Inches
(oC) (oF)
-29 to 66 -20 to 150 300 1500 2000 1000
93 200 265 1350 1785 910
121 250 225 1200 1575 825
149 300 185 1050 1360 735
177 350 150 900 1150 650
204 400 - 750 935 560
232 450 - 600 725 475
260 500 - 450 510 385
288 550 - 300 300 300

We keep Ready Stock of A234 WP1 Reducer, check weight chart and Dimensions of SA234 Grade WP1 Buttweld Fittings

Alloy Steel WP1 Buttweld Fittings Schedule Chart

Buy from PED approved ASTM A234 Gr. WP1 Buttweld Elbow manufacturer for quality products & accurate dimensions

Pipe Fittings
DN Schedule 10S Schedule 40S
45° Elbow 90° Elbow Equal tee Stub end type (B) End cap 45° Elbow 90° Elbow Equal tee End cap Stub end type (B)
15 0.03 0.06 0.09 0.07 0.03 0.04 0.08 0.10 0.04 0.08
20 0.03 0.07 0.13 0.09 0.05 0.04 0.08 0.17 0.07 0.11
25 0.08 0.14 0.28 0.16 0.08 0.11 0.15 0.29 0.10 0.17
32 0.11 0.23 0.49 0.22 0.10 0.17 0.26 0.59 0.18 0.25
40 0.17 0.30 0.68 0.25 0.11 0.23 0.40 0.86 0.20 0.31
50 0.25 0.50 0.85 0.43 0.13 0.40 0.70 1.28 0.23 0.61
65 0.48 0.85 1.41 0.57 0.19 0.77 1.40 2.19 0.27 0.80
80 0.63 1.25 1.77 0.72 0.25 1.08 2.20 3.31 0.42 1.13
100 1.08 2.10 3.46 1.09 0.68 1.47 4.47 5.27 1.14 1.87
125 1.82 3.65 5.44 1.47 1.11 2.84 6.80 9.63 2.13 2.79
150 2.72 5.45 8.03 2.15 1.42 5.44 10.89 10.99 3.23 3.57
200 5.33 10.20 15.65 3.22 2.38 10.77 21.54 20.91 5.19 6.07
250 9.75 18.15 26.76 5.13 4.45 19.27 38.56 35.38 9.00 10.07
300 13.62 25.80 39.46 8.16 7.50 29.71 59.42 62.14 15.00 14.29
350 18.37 36.29 48.53 10.88 8.17 35.15 79.38 79.31 16.00 17.14
400 23.81 47.63 58.97 12.70 10.67 45.81 99.79 99.79 21.00 20.41
450 29.94 59.87 79.65 17.23 13.00 59.40 129.73 129.73 26.00 27.21
500 49.90 99.80 103.42 21.77 17.00 74.84 162.38 162.39 34.00 29.94
600 70.31 140.61 155.58 27.21 26.00 105.23 225.89 225.90 52.00 38.55

ASTM A234 WP1 Fittings Chemical Composition

Cr Mn C Si P S Mo
- 0.30- 0.90 0.28 max 0.10- 0.50 0.045 max 0.045 max 0.044-0.65 max

Alloy Steel WP1 Pipe Fittings Mechanical Properties

RishabhSteel is a industrial Alloy Steel A234 WP1 Pipe Fittings Manufacturers in India since 2001, Quality Assurance, and Reliable Delivery globally

(Mpa) Yield Properties (Mpa) Tensile Properties Elongation %
≥415 min 220 min ≥20
Supplier of SA 234 WP1 Seamless Long/ Short Radius Elbow and ASTM A234 Gr WP1 Concentric Reducer as per ASME B16.9 specification

CrMo ASTM A234 WP1 Elbow Size Chart

Elbow Pipe Fittings
PIPE NOMINAL SIZE OUTSIDE DIAM. 90° ELBOW 45° ELBOW 180° RETURNS
(inches) Short Radius Long Radius Long Radius Long Radius
(mm) (inches) Center to Face
(inches)
Center to Face
(inches)
Radius
(inches)
Center to Face
(inches)
Back to face
(inches)
Center to Center
(inches)
3/4 26.7 1.050 1 1/8 7/16 1 11/16 2 1/4
1/2 21.3 0.840 1 1/2 5/8 1 7/8 2
1 33.4 1.315 1 1 1/2 7/8 2 3/16 3
1 1/2 48.3 1.900 1 1/2 2 1/4 3 1 1/8 3 1/4 4 1/2
1 1/4 42.2 1.660 1 1/4 1 7/8 1 2 3/4 3 3/4
2 60.3 2.375 2 3 4 1 3/8 4 3/16 6
3 88.9 3.500 3 4 1/2 6 2 6 1/4 9
2 1/2 73.0 2.875 2 1/2 3 3/4 5 1 3/4 5 3/16 7 1/2
3 1/2 101.6 4.000 3 1/2 5 1/4 7 2 1/4 7 1/4 10 1/2
5 141.3 5.563 5 7 1/2 10 3 1/8 10 5/16 15
4 114.3 4.500 4 6 8 2 1/2 8 1/4 12
6 168.3 6.625 6 9 12 3 3/4 12 5/16 18
10 273.1 10.750 10 15 15 6 1/4 20 3/8 30
8 219.1 8.625 8 12 12 5 16 5/16 24
12 323.9 12.750 12 18 18 7 1/2 24 3/8 36
Looking for ASTM A234 WP1 Pipe cap manufacturer in India for custom design? Mail us to get RFQ for A234 WP1 Material within 24 hours

ASTM A234 Grade WP1 Fittings Wall Thickness

Why don't you directly contact a Alloy Steel A234 WP1 Tee manufacturer in Mumbai? We offer Non chinese ASME/ANSI B16.9 Alloy Steel WP1 Reducer and ANSI B16.28 WP1 Alloy Steel Tee in India

O.D. (mm) Nominal Pipe Size W.T. (mm)
Sch 5S Sch 10S Sch 40S Sch 80S
NPS DN Weight (kg/m) WT (mm) Weight (kg/m) WT (mm) Weight (kg/m) WT (mm) Weight (kg/m) WT (mm)
10.3 6 0.28 1.24 0.37 1.73 0.47 2.41
13.7 ¼ 8 0.49 1.65 0.63 2.24 0.80 3.02
17.1 10 0.63 1.65 0.84 2.31 1.10 3.20
21.3 ½ 15 0.80 1.65 1.00 2.11 1.27 2.77 1.62 3.73
26.7 ¾ 20 1.02 1.65 1.28 2.11 1.69 2.87 2.20 3.91
33.4 1 25 1.29 1.65 2.09 2.77 2.50 3.38 3.24 4.55
42.2 32 1.65 1.65 2.69 2.77 3.39 3.56 4.47 4.85
48.3 40 1.90 1.65 3.11 2.77 4.05 3.68 5.41 5.08
60.3 2 50 2.39 1.65 3.93 2.77 5.44 3.91 7.48 5.54
73.0 65 3.69 2.11 5.26 3.05 8.63 5.16 11.41 7.01
88.9 3 80 4.52 2.11 6.46 3.05 11.29 5.49 15.27 7.62
101.6 90 5.18 2.11 7.41 3.05 13.57 5.74 18.64 8.08
114.3 4 100 5.84 2.11 8.37 3.05 16.08 6.02 22.32 8.56
141.3 5 125 9.46 2.77 11.56 3.40 21.77 6.55 30.97 9.53
168.3 6 150 11.31 2.77 13.83 3.40 28.26 7.11 42.56 10.97
219.1 8 200 14.78 2.77 19.97 3.76 42.55 8.18 64.64 12.70
273.1 10 250 22.61 3.40 27.79 4.19 60.31 9.27 81.56 12.70
323.9 12 300 31.25 3.96 35.99 4.57 73.88 9.53 97.47 12.70
355.6 14 350 34.34 3.96 41.36 4.78 81.33 9.53 107.40 12.70
406.4 16 400 41.56 4.19 47.34 4.78 93.27 9.53 123.31 12.70
457 18 450 46.79 4.19 53.31 4.78 105.17 9.53 139.16 12.70
508 20 500 59.32 4.78 68.65 5.54 117.15 9.53 155.13 12.70
559 22 550 65.33 4.78 75.62 5.54
610 24 600 82.58 5.54 94.53 6.35 141.12 9.53 187.07 12.70
660 26 650
711 28 700
762 30 750 118.34 6.35 147.29 7.92

Alloy Steel WP1 Seamless Fittings Applications

Why pay extra? Buying from Alloy Steel 5Cr-1/2Mo Welded Fittings manufacturers saves your cost, wide selection of Chrome Moly Alloy Steel Grade WP1 Seamless Pipe Fittings and ASME SA234M Alloy Steel WP1 Pipe Cap in India


  • Textile machinery
  • Oil and gas industry
  • Pulp and paper industry
  • Power plants
  • Energy industries
  • Furniture
  • Modern architecture
  • Home appliances
  • Water waste projects
  • Synthetic fiber
  • Heat exchanger
  • Fluid piping
  • Dairy and food processing
  • Pharmaceutical processing industry
